Appendix D: Vehicle Power Management Setup

a d: V
PPendIx

Entering BIOS Menu

In the BIOS menu, go to Advanced→Power Management Configuration.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Main Advanced Security
Trusted Computing

Power Management Configuration

Module Management

ACPI Settings

NCT6106D Super IO Configuration

NCT6106D HW Monitor

CPU Configuration

SATA Drives

Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
P
ehICle ower
Boot Save & Exit Save & Exit
Trusted Computing Settings
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
m
anaGement

Startup and Shutdown Voltage Setting

Set the startup voltage to 11.5V or 23V and the shutdown voltage to 10.5V or 21V
If the input voltage is 12V: the startup voltage to 11.5V and the shutdown
voltage to 10.5V.
If the input voltage is 24V: the startup voltage to 23V and the shutdown
voltage to 21V.
Aptio Setup Utility - Copyright (C) 2016 American Megatrends, Inc.
Advanced
Power Management Configuration settings
Input Voltage
Startup,Shutdown
Delay Time Setting
Power On Delay
Power Off Delay
56
s
etuP
[9~36V]
[(11.5,10.5)/(23,21)]
[Disable]
[Disable]
Startup,Shutdown
(11.5, 10.5) / (23,21)
(12.0, 11.0) / (24,22)
(12.5, 11.0) / (25,22)
(12.5, 11.5) / (25,23)
Version 2.18.1263. Copyright (C) 2016 American Megatrends, Inc.
Startup,Shutdown Setting.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
