EUROCOM M590KE EMPEROR-X User Manual page 40

Concise User's Guide
8. As the computer boots up you will see the screen below (press F10 to enter the utility).
9. The MediaShield ROM BIOS Utility will then appear (if you have not previously set up an array then you will be presented
with the "Define a New Array" menu).
10. Press Tab to navigate through the menu options, the up/down arrow keys to move up and down the drop-down menus, and
Enter to select an option.
11. Any available free hard disks will appear in the menu on the left, and these may be moved into (and removed from) the array
by means of the left/right arrow keys.
MediaShield Utility
- Define a New Array -
RAID Mode : Mirroring
Free Disks
Port Disk Model Capacity
2.0 TOSHIBA MK8032 74.53GB
2.1 TOSHIBA MK8032 74.53GB
[ESC] Quit [F6] Back [F7] Finish
34 - RAID Configuration
MediaShield ROM BIOS 6.75
Copyright (C) 2006 NVIDIA Corp.
Detecting array ...
0 Healthy NVIDIA MIRROR
Press F10 to enter RAID setup utility ...
Figure 15 - MediaShield ROM BIOS Screen
JuN 23 2006
Striping Block: Optimal
Array Disks
Loc Disk Model Capacity
[ ] Add
[ ] Del
[TAB] Navigate [ ] Select [ENTER] Popup
Figure 16 -
MediaShield ROM BIOS (Define New Array)
74.53G
MediaShield Utility
- Define a New Array -
RAID Mode : Mirroring
Free Disks
Port Disk Model Capacity
[ ] Add
[ ] Del
[ESC] Quit [F6] Back [F7] Finish [TAB] Navigate [
Jun 23 2005
Striping Block: Optimal
Array Disks
Port Disk Model Capacity
2.0 TOSHIBA MK8032 74.53GB
2.1 TOSHIBA MK8032 74.53GB
] Select [ENTER] Popup
