RAID Mode Setup
1. Install two identical serial hard disk drives (see the expanded English language User's Manual on the Device Drivers & Utili-
ties + User's Manual CD-ROM for details on installing the hard disks).
2. Prepare a formatted blank 3.5" 1.44MB floppy diskette, and an external USB floppy disk drive.
3. Create a RAID Driver Diskette by using an operable computer to copy the contents of the sataraid folder from the Device
Drivers & Utilities + User's Manual CD-ROM (Navigate/Browse.. to D:Drivers\00CHIPSET\IDE\WinXP\sataraid) to the
blank floppy diskette.
4. Startup your computer and press <F2> to enter the BIOS.
5. Go to the Advanced > Advanced Chipset Control menu and set the "NV RAID Configuration:" item to Enabled.
6. Go to the Boot menu and select the CD-ROM/DVD-ROM as the first device in the "Boot priority order" by pressing the
<Shift> and <+> keys to move the CD-ROM/DVD-ROM to the top of the order.
7. Make sure that the computer is connected to the AC power source, and press F10 to save the changes, and exit the BIOS.
PhoenixBIOS Setup Utility
Advanced Advanced
Advanced Chipset Control
NV RAID Configuration: [Enabled]
Audio Codec: [Auto]
Modem Codec: [Auto]
Route Port 80h cycles to [LPC]
F1 Help Select Item -/+
Exit Select Menu
Esc Enter
Item Specific Help
Enable/Disable
Nvidia RAID control.
SATA controller must
be enabled for RAID
feature to function.
Enabling Master SATA0
Secondary requires
enabling Secondary SATA
Channel.
Both options are listed
in Integrated Devices.
Change Values F9 Setup Defaults
Select Sub-Menu Save and Exit
F10
Figure 14 - BIOS Menus
PhoenixBIOS Setup Utility
Main Advanced Security
Boot priority order:
1: IDE CD: UJDA770 DVD/CDRW-(PM)
2: USB FDC:
3: USB KEY:
4: PCI SCSI: TOSHIBA MK8032GSX
5: PCI BEV:
6:
7:
8:
Excluded from boot order:
: USB HDD:
: USB CDROM:
F1 Help Select Item -/+
Esc Exit Select Menu Enter
Concise User's Guide
Exit
Boot
Item Specific Help
Keys used to view or
configure devices:
Up and Down arrows
select a device.
<+> and <-> moves
the device up or down.
<x> exclude or include
the device to boot.
Change Values F9 Setup Defaults
Select Sub-Menu F10 Save and Exit
RAID Configuration - 33
