Service Manual
H1F Bent Axis Fixed Displacement Motors, Size 080
H1 general information

H1F system schematic

System schematic H1 pump and H1F motor
M14
C2
F00B F00A
M5
M4
The schematic above shows the function of a hydrostatic transmission using an H1 axial variable displacement pump with electric
proportional displacement control (EDC) and an H1 fixed displacement motor with integrated loop flushing device.
© Danfoss | December 2023
M6 1 2
R1
C1
CW
S L3 L4
max. 3 bar
[43.5 psi]
M3 L1 L2 MA
A A
B B
MB
L2 L3
AX465363259664en-000102 | 9
N
n
L1
