Service Manual
H1F Bent Axis Fixed Displacement Motors, Size 080
Technical specifications
H1F General specifications
H1F Physical properties
10 |
©
Danfoss | December 2023
General specifications
Design
Direction of rotation
Pipe connections
Recommended installation
Physical properties
Features
Displacement (max)
Theoretical flow at max. displ.
Theoretical torque
at max. displacement
Theor. corner power at rated speed and max. working
pressure (∆p = 450 bar [6527 psi])
Mass moment of inertia of rotating components
Case volume
Weight dry
Configuration
SAE
DIN
Cartridge
Mounting flange
Configuration
SAE ISO 3019/1
DIN ISO 3019/2, B4
Piston motor with fixed displacement bent axis design
Bi-directional
Main pressure ports: ISO split flange boss
Remaining ports: SAE straight thread O-ring boss
Discretionary, the housing must always be filled with hydraulic fluid
Unit
cm
at rated speed
l/min
[US gal/min]
at max. speed
N•m/bar
[lb•in/1000 psi]
kW [hp]
kg•m
[slug•ft
l [US Gal]
080
22.1 kg [48.7 lb]
22.9 kg [50.5 lb]
23.3 kg [51.4 lb]
080
3
3
80.8 [4.93]
[in
]
320 [84.5]
400 [105.7]
1.27 [777]
330 [442.5]
2
0.006320
2
]
[0.00466]
0.8 [.21]
Size
Size
080
127-4 (SAE C) 4-bolt
140 HL 4-bolt
AX465363259664en-000102
Size
