Service Manual
H1F Bent Axis Fixed Displacement Motors, Size 080
Operating parameters

External shaft seal pressure

Temperature

18 | © Danfoss | December 2023
C
Caution
Possible component damage or leakage.
Operation with case pressure in excess of stated limits may damage seals, gaskets, speed sensors and/or
housings, causing external leakage. Performance may also be affected since charge and system pressures
are referenced to case pressure.
In certain applications, the output shaft seal may be exposed to external pressures. The shaft seal is
designed to withstand an external pressure up to 0.25 bar [3.6 psi] above the case pressure. The case
pressure limits must also be followed to ensure the shaft seal is not damaged.
The high temperature limits apply at the hottest point in the transmission, which is normally the motor
case drain. The system should generally be run at or below the published rated temperature.
The maximum intermittent temperature is based on material properties and should never be
exceeded.
Cold oil will generally not affect the durability of the transmission components, but it may affect the
ability of oil to flow and transmit power. Therefore, temperatures should remain 16 °C [30 °F] above the
pour point of the hydraulic fluid.
The minimum temperature relates to the physical properties of component materials.
Size heat exchangers too keep the fluid within these limits. Danfoss recommends testing to verify that
these temperature limits are not exceeded.
