Directed DIRECTECHS DB3 Installation Manual

For 2008 subaru impreza
Hide thumbs Also See for DIRECTECHS DB3:
Table of Contents

Advertisement

Quick Links

Download this manual
Functions compatible with the 2008 Subaru Impreza
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Trunk/Hatch Pin
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Key2GO
Remote Start Takeover
SmartStart
Tach / RPM Output
Trunk / Hatch Release
403.SUBARU1
v1.38
2008 Subaru Impreza

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTECHS DB3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Directed DIRECTECHS DB3

Summary of Contents for Directed DIRECTECHS DB3

  • Page 1 403.SUBARU1 v1.38 2008 Subaru Impreza Functions compatible with the 2008 Subaru Impreza Arm Factory Security Entry Monitoring Trunk/Hatch Pin Brake Status (foot brake) Ignition Status Control of aftermarket alarm with OEM remote Immobilizer Bypass-Data No Key Req'd Disarm Factory Security Key2GO Door Lock Control Remote Start Takeover...
