Operating Instructions
Original Operating Instructions
Cubis
®
MCA Models
Microbalances
1000047994

Advertisement

Table of Contents
loading

Related Manuals for Sartorius Cubis MCA Series

Summary of Contents for Sartorius Cubis MCA Series

  • Page 1 Operating Instructions Original Operating Instructions Cubis ® MCA Models Microbalances 1000047994...

  • Page 3: Table Of Contents

    Contents Contents 1 About these Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 4 .9 Buttons in the Operating Display .
  • Page 4 Contents 7 .5 Parameter List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 8 Operation .
  • Page 5 17 Sartorius Service . . . . . . . . . . . . . . . . . . .

  • Page 6: About These Instructions

    About these Instructions About these Instructions Scope These instructions are part of the device . These instructions apply to the device in the following versions: Device Model Ultramicrobalance and microbalance MCA10 .6S . . .-M | MCA2 .7S . . .-M | with motorized draft shield MCA3 .6P .

  • Page 7: Target Groups

    About these Instructions Target Groups These instructions are addressed to the following target groups . The target groups must possess the specified knowledge . Target group Knowledge and responsibilities User The user is familiar with the operation of the device and the associated work processes .

  • Page 8: Safety Instructions

    If the device is modified, for example by attaching extra components: Device safety may be affected, or the device may cease to be compliant . If you have any queries regarding modifications to the device, contact Sartorius . 2.1.2 Repairs to the Device Device repairs may only be carried out by persons with appropriate specialized knowledge of the device .

  • Page 9: Significance Of These Instructions

    Working on the Device's Electrical Equipment Only Sartorius Service personnel may work on or modify the electrical equipment of the device . The device may only be opened by Sartorius Service personnel . 2.6.3 Power Supply Unit and Power Supply Cable Serious injury can result, e .g .

  • Page 10: Cable

    − Risk of injury to persons − Damage to the device − Device malfunctions − Device failure Only use approved accessories and spare parts supplied by Sartorius . Only use accessories, consumables, and spare parts that are in proper working order . Glass Breakage Glass components can break if they fall or are handled incorrectly .

  • Page 11: Device Description

    Device Description Device Description Device Overview Fig . 1: Microbalance with glass draft shield and electronics module (example) Pos. Name Description Leveling foot Motorically adjustable Not depicted Manufacturer’s ID label Electronics module Operating display Touchscreen Palm-operated key Only for microbalance with motorized draft shield: Opens and closes draft shield . Control unit Weighing module Weighing chamber...

  • Page 12: Draft Shield

    Device Description Draft Shield Fig . 2: Microbalance with motorized glass draft shield and filter microbalance with manual metal ring draft shield (example) Pos. Name Description Metal ring draft shield cover Made from metal, with handle, can be removed . Metal ring draft shield Consists of 2 metal rings that have been placed into each other with a side opening, can be rotated manually .

  • Page 13: Weighing Pan And Associated Components

    Device Description Weighing Pan and Associated Components Fig . 3: Microbalance with motorized glass draft shield and filter microbalance with manual metal ring draft shield (example) Pos. Name Description Filter weighing pan Shield plate Connector For models MCA2 .7S . . . only Pan retainer Internal draft shield For models MCA2 .7S .

  • Page 14: Connections On The Control Unit

    Access switch Protects the device from changes to the device settings . Is sealed for conformity- assessed devices . Peripheral connection For connecting Sartorius accessories Weighing module connection For connecting the electronics module to the weighing module Power supply For connection to the power supply Cubis ®...

  • Page 15: Safety Equipment

    Device Description Safety Equipment 3.7.1 Protective Caps on the Electronics Module Fig . 7: Protective caps on the electronics module Pos. Name Description Protective cap for USB-A connection Plastic attachment hood, fastened to the device . Protective cap for USB-B connection Plastic attachment hood, fastened to the device .

  • Page 16: Motorized Draft Shield

    Device Description Motorized Draft Shield 3.9.1 Sensor Area The device has a motion sensor that opens the draft shield automatically as soon as a motion is detected within the sensor area . Following that the draft shield will be automatically closed again . The operation is optimized for left- and right-handed users due to the motion sensor .

  • Page 17: Operating Concept

    Operating Concept Operating Concept Operating Elements in the Main Menu Fig . 1: Operating elements in the main menu (example) Pos. Name Description Navigation and function bar − Enables navigation and searching in menus and lists . − In the “Settings” Menu: Displays the name of the menu . Available tasks Displays all tasks available for the active user .

  • Page 18: Operating Elements In Task Management

    Operating Concept Operating Elements in Task Management Fig . 2: Operating elements in Task Management (example) Pos. Name Description Navigation and function bar − Enables navigation and searching in menus and lists . − Enables the addition of tasks . −...

  • Page 19: Operating Elements In The Weighing Display

    Operating Concept Operating Elements in the Weighing Display Fig . 3: Weighing display (example) Pos. Name Description Application symbol Displays the symbol for the active application . Task name Displays the name of the active task . Date display Displays the current date . User name Displays the name of the active user profile .

  • Page 20: Advanced Operator Guidance

    Operating Concept Advanced Operator Guidance Advanced applications have advanced operator guidance . Fig . 4: Advanced operator guidance (example) Pos. Name Description Weighing display with operator guidance Advanced operator guidance Guides the user through the active task . Includes 2 or 3 convertible displays depending on the selected application: −...

  • Page 21: Messages

    Operating Concept Messages Fig . 5: Error message (example) Pos. Name Description Description Specifies the cause . Remedy Specifies the measures necessary to eliminate the cause of the message . Confirm Confirms and closes the message . Message type Indicates that the message is a status message, warning message, or an error message .

  • Page 22: Status Center

    Operating Concept Status Center Fig . 6: Status Center (example) Pos. Name Description Messages Displays information, warning, and error messages . Leveling status Displays the status of the level . Status for the device Displays the general device information . Calibration and adjustment report Displays the data for the last adjustment and calibration .

  • Page 23: Keypad

    Operating Concept Keypad The keypad is used for entering values in entry fields . If an entry field is activated: The alphanumeric keypad or numerical keypad appears . Fig . 7: Alphanumeric keypad and numerical keypad (example) Pos. Name Description Entry field Input assistance Indicates which values must be entered in the input field, e .g .

  • Page 24: Buttons In The Operating Display

    Operating Concept Buttons in the Operating Display 4.9.1 Buttons for Navigation or Organization in Displays Symbol Name Description [Menu] button Quits the active task and opens the main menu . [Back] button − Returns to the previous display . − In the main menu: Accesses the last-performed task . [Search] button Displays options for browsing tasks and list elements .

  • Page 25: Buttons For Editing Or Managing Entries

    Operating Concept Symbol Name Description [Service Information] button Opens the “Settings” / “Device Settings” / “Device Information” / “Service” Service menu . Information [Status Archive] button Opens an overview of all status messages, warning messages, and error Archive messages . [Leveling] button Opens the Leveling Wizard .

  • Page 26: Weighing And Print Function Buttons

    Operating Concept Symbol Name Description [Edit] button Accesses the Adjustment Wizard for editing the displayed element, e .g . for setting the parameters for a task . [Delete] button Deletes the selected element . [User Activated] button Logs in a deactivated user . [User Deactivated] button Logs out the currently logged-in user .

  • Page 27: Displays In The Operating Display

    Operating Concept Symbol Name Description [Quit] button Quits the active application and opens the Print Memory display . [Confirm] button Confirms the current display and initializes the next step . [Save] button Saves the weight value and sends it to the print memory . [Print memory] button Opens the Print Memory display .
  • Page 28 Operating Concept Symbol Name Description [Current page] display − Indicates that the current display is a multi-page display . − Indicates which page of a multi-page display is being displayed currently . [Copy] button Indicates that data are being copied . [Selection] display Indicates that an entry is selected in a list .

  • Page 29: User Management

    Operating Concept 4.11 User Management 4.11.1 User Profiles In the factory, 4 user profiles are created for the device . One role is assigned to each user profile . Each role has rights to operate the device . The rights assigned to each role depend on which device functions the user has to use .

  • Page 30: Menu Structure

    Display the certification body's SHA1 fingerprint . fingerprint HTTPS certificate SHA1 Display the HTTPS certificate’s SHA1 fingerprint . fingerprint Service Service contact Display the responsible contact at Sartorius Service . Telephone number Display the telephone number for Sartorius Service . Cubis ®...
  • Page 31 Operating Concept Level 1 Level 2 Level 3 Description E-mail Display the e-mail address for Sartorius Service . Hotline Display the technical hotline for Sartorius Service . Contract Display the responsible contact for maintenance measures . Next scheduled maintenance Display the date for the next scheduled maintenance .
  • Page 32 Operating Concept Level 1 Level 2 Level 3 Description Timer-controlled Start task Display, edit or delete properties for starting the actions task . Display message Display, edit or delete the message name and content . Standby mode Display, edit or delete execution of the action for standby mode .
  • Page 33 Operating Concept Level 1 Level 2 Level 3 Description Website / web services Website access Determines the settings for the display of the website for the device . Remote access Define the settings for controlling the device remotely . Web service password Define the password for the web services .
  • Page 34 Operating Concept Level 1 Level 2 Level 3 Description Left sensor sensitivity range Define the sensitivity for the left sensor window of the motion sensor . Only for devices with a motorized draft shield . Right sensor sensitivity range Define the sensitivity for the right sensor window of the motion sensor .
  • Page 35 Operating Concept Level 1 Level 2 Level 3 Description Update the firmware . The menu is not available Device Update firmware USB stick maintenance for conformity-assessed devices . Refreshed QAPP center USB stick Update the QAPP center using the connected USB stick .

  • Page 36: Navigating The Menus

    Operating Concept 4.15 Navigating the Menus Procedure To open a menu from the main menu: Tap on the desired menu button in the function bar . The menu opens and the name of the open menu is displayed in the navigation bar .
  • Page 37 Operating Concept If elements from a display need to be filtered or a display needs to be browsed: Press the [Search] or [Filter] button . The keypad is displayed . Type the searched value or value to be filtered into the entry field (1) using the keypad .

  • Page 38: Installation

    Installation Installation Scope of Delivery Item Quantity Device Weighing pan Filter Ultramicrobalances and Microbalances: Filter weighing pan For models MCA2 .7S . . .: Internal draft shield Shield plate For models MCA2 .7S . . .: Connector AC adapter For models with a motorized draft shield: Palm-operated key Country-specific power supply cable with test seal USB connection cable In-use dust cover for display and control unit...

  • Page 39: Unpacking The Device

    Installation Unpacking the Device Procedure Lift the device with the styrofoam padding out of the packaging . Place the device in the styrofoam padding on its side . Lift the styrofoam padding off the device . CAUTION Incorrect handling of the device may cause glass to break! Do not lift the device by the draft shield .

  • Page 40: Procedure

    Installation Procedure Turn the device on its side and place it on the soft support base . Unscrew both screws (2) from beneath the weighing module with the Torx Allen key . Lift out the cover plate (1) . Install a draft protection shield . Set up the device on the weighing table with recess .

  • Page 41: Installing A Filter Balance With A Metal Ring

    Installation Place the weighing pan (1) through the opening in the base of the weighing chamber into the pan retainer . To mount the weighing pan: Turn the weighing pan slightly while pressing down lightly . For devices with an internal draft shield: Place the internal draft shield on a shield plate .

  • Page 42: Optimizing A Filter Weighing Pan With

    Installation Insert the bearing pin (1) into the recess of the draft shield . Place the draft shield cover on the draft shield . 5.8.2 Optimizing a Filter Weighing Pan with a Metal Ring Draft Shield for Left-handed Users Requirements The metal ring draft shield has been mounted .

  • Page 43: Installing Palm-Operable Keys

    Installation 5.10 Installing Palm-operable Keys (Only for Devices with Motorized Draft Shield) For models with a motorized draft shield, 2 palm-operable keys can be installed . Procedure Affix both palm-operable keys (1) onto the side of the display and control unit . 5.11 Acclimatizing When a cold device is brought into a warmer area: The temperature difference can lead to condensation of humidity in the device (moisture formation) .

  • Page 44: Getting Started

    WARNING Severe injuries caused by using a defective power supply cable! Check the power supply cable for damage, e .g ., cracks in the insulation . If required: Contact Sartorius Service . Check whether the country-specific power plug matches the power connections at the installation site .

  • Page 45: Attaching The Protective Caps

    Getting Started Attaching the Protective Caps If connections of the device are not being used during operation: The connections must be sealed with the protective caps supplied . Procedure Check whether all unused connections have been sealed with a protective cap . Place the protective caps (1) for the electrical connections on the unused connections .

  • Page 46: System Settings

    System Settings System Settings Performing System Settings Default settings can be adjusted for the device and the applications in order to align with the ambient conditions and individual operating requirements . The following settings are necessary to operate the device together with connected components: −...

  • Page 47: Setting Up Device For Network Printer

    System Settings Setting Up Device for Network Printer 7.4.1 Selecting Configuration for Network Printing Two configurations are possible: − The device and the network printer communicate via an independent Wi-Fi network with standard Wi-Fi components . No security guidelines or network settings need to be taken into consideration here .

  • Page 48: Via Company Network

    System Settings 7.4.3 Setting Up Device for Network Printer via Company Network Requirements − The device administrator or service rights are activated via user management . − The company network has a DHCP server . − The network printer is connected to the company network . Procedure Open the “Settings / Connections / Network / Wi-Fi”...

  • Page 49: Parameter List

    . Language Set the language for the user profile . User color profile Sartorius Standard* If the QAPP extension “Color Scheme” has been activated: Define a user color for the user profile . Login method Determine whether the user password is saved locally on the device or provided by an LDAP network server .

  • Page 50: Parameters In The "Timer-Controlled

    System Settings 7.5.3 Parameters in the “Timer-Controlled Actions” Menu Parameter Settings Explanation Start task Execution date Activates the date and time for starting the task . Repeat period Repeats in minutes, hours, days, months, or years . Name Saves a name for the timer-controlled action . Sets the execution of the action to cancelable or not cancelable .

  • Page 51: Profiles / Weighing" Menu

    System Settings 7.5.4 Parameters in the “Weighing and Print Profiles / Weighing” Menu Parameter Settings Explanation Ambient conditions Very stable Sets the ambient conditions to “very stable”: Activates a fast change in the weight values in the event of a load change with a high output rate . Recommended for the following work environment: −...
  • Page 52 System Settings Parameter Settings Explanation Stability delay Very short Sets the stability delay to “very short”: The stability symbol is displayed after the stability criterion is reached . Short* Sets the stability delay to “short”: The stability symbol only appears after a short delay in order to provide a reliable result despite fluctuations .

  • Page 53: Or Sbi Direct" Menu

    Prints an entered description, e .g . the name of the print profile . User text 2 Prints an additional entered description . Manufacturer Prints the device manufacturer, e .g . “Sartorius” Model name Prints the device model name . Serial number Prints the device serial number .

  • Page 54: Parameters In The "Connections

    System Settings Parameter Settings Explanation Last calibration Prints the date/time of the last calibration/adjustment . Device ID 1 Prints the entered device ID 1 . Device ID 2 Prints the entered device ID 2 . Date/time Prints the current date and time . Time zone Prints the name of the selected time zone .

  • Page 55: Parameters In The "Connections / Network" Menu

    System Settings Parameter Settings Explanation Network printer Connector name Saves the entered name for a USB stick . IP or host Enter the IP or host address for the printer . Protocol Define the protocol for the printer: Socket, IPP, HTTP or LDP Connector name If the QAPP extension “Windows File Server”...

  • Page 56: Parameters In The "Connections / Interfaces / Serial Communication Via

    System Settings 7.5.9 Parameters in the “Connections / Interfaces / Serial Communication via Network” (Ethernet) Menu Parameter Settings Explanation Protocol Deactivates the serial transmission via Ethernet . SBI* Enables SBI communication . The data is output to a PC or control unit . Enables the use of ESC commands from a PC to control the basic balance functions with ASCII protocol .

  • Page 57: Parameters In The "Connections / Interfaces / Usb-B Interface" Menu

    System Settings 7.5.11 Parameters in the “Connections / Interfaces / USB-B Interface” Menu Parameter Settings Explanation Protocol Off* Deactivates the USB-B connection . Enables SBI communication . The data is output to a PC or control unit . Enables the use of ESC commands from a PC to control the basic balance functions with ASCII protocol .

  • Page 58: Parameters In The "Connections / Connected Devices / Motion Sensor" Menu (Only For Connected Motion Sensors)

    System Settings 7.5.14 Parameters in the “Connections / Connected Devices / Motion Sensor” Menu (Only for Connected Motion Sensors) Parameter Settings Explanation Number of gestures 2 gestures (left, right)* Activates the control of functions with 2 gestures . Gestures: left, right . 4 gestures (left, right, up, Activates the control of functions with 4 gestures .

  • Page 59: Safe Weighing" Menu

    System Settings 7.5.16 Parameters in the “Device Settings / Safe Weighing” Menu Parameter Settings Explanation Deactivates the isoCAL function . This setting change is not available for all isoCAL execution mode models . Show status field, manual If the device must be calibrated: The [isoCAL] button is displayed as the start predominant button in the operating display .

  • Page 60: Parameters In The "Device Settings / Draft Shield" Menu

    System Settings 7.5.19 Parameters in the “Device Settings / Draft Shield” Menu (Only for Devices with a Motorized Draft Shield) Parameter Settings Explanation Left/right palm key Off, no function Deactivates the function for both palm-operated keys . Same function Assigns the same function to the palm-operated keys . The two palm- operated keys cannot be assigned functions independently of each other .

  • Page 61: Electronic Signature" Menu

    ON key . Color scheme Sartorius Standard* If the QAPP extension has been activated: Selects the color scheme for the “Sartorius Standard” operating display . Additional color schemes can be unlocked via the QAPP center . * Factory setting Cubis ®...

  • Page 62: Sound (Loudspeaker)" Menu

    System Settings 7.5.23 Parameters in the “Device Settings / Sound (Loudspeaker)” Menu Parameter Settings Explanation Touch sounds Activated Deactivates the acoustic signal for touch and keypad operation . Deactivated* Activates the acoustic signal for touch and keypad operation . Message sounds Activated Deactivates the acoustic signal for messages .

  • Page 63: Operation

    Operation Operation Switching the Device On and Off The device only delivers accurate values if it has reached the necessary operating temperature . The warm-up time after switching the device on must therefore be complied with . If the device is being switched on for the first time or if the device is switched on after being reset to factory settings: The Setup Wizard opens .

  • Page 64: Leveling The Device

    Operation Leveling the Device 8.3.1 Leveling the Device Leveling compensates any inclines at the device’s installation site . If leveling is necessary: The [Leveling] button appears in the weighing display and a message appears in the Status Center . Procedure If the weighing display is displayed: Press the [Leveling] button .

  • Page 65: Defining The Opening Width

    Operation 8.4.1 Defining the Opening Width It can be determined how far the draft shield should open when pressing the palm-operated key . The opening width of the draft shield can be determined separately for each palm-operated key . Procedure Same function Separate Function (one opening angle)

  • Page 66: Adding An Application To A Task

    Operation If an individual application from the displayed QAPP package is to be activated: Press the desired application . A display opens containing details about the selected application . Press the [License] button . The input field for the license key appears . If an additional cost is associated with the application: Enter the license key in the entry field and press the [OK] button .

  • Page 67: Weighing

    Operation Weighing NOTICE Chemicals may damage the device or accessories! Chemicals can attack the device or the connected accessories internally and externally . This may damage the device and accessories . Use appropriate containers when weighing chemicals . Procedure Start a task with weighing function . Zero the device .

  • Page 68: Adjusting With The Isocal Function

    Operation 8.10 Adjusting with the isoCAL Function The device can be automatically internally calibrated and adjusted using the isoCAL function . Requirements − The device is not located in the menu . − Alphanumeric inputs are not active . − The load on the weighing pan remains unchanged for 2 minutes . −...

  • Page 69: Internally Calibrating And Adjusting The Device

    Operation 8.11 Internally Calibrating and Adjusting the Device Requirements The weighing pan is unloaded . Procedure Open the main menu . Select the “Internal Adjustment” task . The internal calibration / adjustment function is executed . If automatic leveling is set for a model with motorized adjusting feet: The device levels itself automatically .

  • Page 70: Marking Saved Values As Invalid

    Operation 8.12.2 Marking Saved Values as Invalid Procedure Press the [Print Memory] button . The print memory opens and a list of all saved values is displayed . Press the desired items . An overview of all data to be printed is displayed for the selected items . Press the [Yes] button .

  • Page 71: Viewing The Data Storage Device

    Operation 8.13 Viewing the Data Storage Device The data storage device stores weight values with date, time, and process number . The content of the data storage device can be searched and sorted using a filter . The data storage device has a ring buffer . This means that the oldest data records can be overwritten by new ones .

  • Page 72: Running The "Statistics" Application

    Operation 8.14.2 Running the “Statistics” Application The “Statistics” application saves up to 100 weight values and evaluates these statistically . The following values are saved and exported by the statistics application: − Number of components − Mean value − Standard deviation −...

  • Page 73: Cleaning And Maintenance

    Cleaning and Maintenance Cleaning and Maintenance Preparing the Device Procedure Turn the device off . Disconnect the device from the power supply . Open the draft shield . Cleaning the Device NOTICE Corrosion or damage to the device due to unsuitable cleaning agents! Do not use corrosive, chloride-containing, or aggressive cleaning agents .

  • Page 74: Assembling And Connecting The Device

    − The software update is saved on a USB mass storage device . Procedure Download the software update from the Sartorius website onto the USB mass storage device . If this relates to a zip file: Unzip the software update on the stick .

  • Page 75: Performing A Qapp Center Update

    − The QAPP center update is saved on a USB mass storage device . Procedure Download the QAPP center update from the Sartorius website onto the USB mass storage device . If this relates to a zip file: Unzip the QAPP center update on the stick .

  • Page 76: Malfunctions

    . control unit and the with the weighing module . weighing module . If the problem occurs again: 17, 87 Contact Sartorius Service . 10.3 Troubleshooting Fault Cause Remedy Chapter, page The operating display The device is disconnected .

  • Page 77: Decommissioning

    Decommissioning 11 Decommissioning 11.1 Decommissioning the Device Procedure Turn the device off . Disconnect the device from the power supply . Disconnect the device from all connected devices and all accessories, e .g . printer or electronics module . Clean the device (see Chapter 9 .2, page 73) . If below-balance weighing has been set up: Turn the device on its side and place it on a soft support base .

  • Page 78: Storage And Shipping

    .g . in the original packaging . Transport damage as well as measures for subsequent cleaning and disinfection of the device or device components by Sartorius shall be charged to the sender . WARNING Risk of injury due to contaminated devices! Devices contaminated with hazardous materials (NBC contamination) will not be accepted for repair or disposal .

  • Page 79: Disposal

    WARNING Risk of injury due to contaminated devices! Devices contaminated with hazardous materials (NBC contamination) will not be accepted by Sartorius for repair or disposal . 14.2 Disposing of Device and Parts 14.2.1 Information on Disposal The device and the device accessories must be disposed of properly by disposal facilities .

  • Page 80: Technical Data

    Technical Data 15 Technical Data 15.1 Dimensions and Weight 15.1.1 Microbalance With round glass ring draft shield With stainless steel draft shield for the filter pan Unit Value Value Dimensions Weighing module (L x W x H) 340 x 139 x 129 340 x 139 x 129 Electronics module with control 355 x 240 x 61...

  • Page 81: Ambient Temperature For The Isocal Function

    Without isoCAL function °C +17 – +27 15.2.3 Protection Class IP Protection: Protected against dust and water 15.3 Power Supply 15.3.1 Device Only by Sartorius AC adapter YEPS03-15V0 15.3.2 AC Adapter Unit Value Item No . YEPS03-15V0 Primary AC voltage 100 –...

  • Page 82: Safety Of Electrical Equipment

    Technical Data 15.3.3 Safety of Electrical Equipment According to EN 61010-1 / IEC 61010-1 Safety requirements for electrical equipment for measurement, control, and laboratory use – Part 1: General Requirements 15.3.4 Electromagnetic Compatibility Interference resistance Suitable for use in industrial areas Transient emissions Class B Suitable for use in residential areas and areas that are...

  • Page 83: Metrological Data

    Technical Data 15.7 Metrological Data 15.7.1 Models MCA2.7S | MCA10.6S | MCA6.6S | MCA3.6P MCA2.7S MCA10.6S MCA6.6S MCA3.6P Unit Value Value Value Value Scale interval (d) µg 0 .1 1 | 2 | 5 Maximum capacity (Max) 2 .1 10 .1 6 .1 1 .1 | 2 .1 | 3 .1 Repeatability at 5% load...

  • Page 84: Isocal Function

    Pin 8: Request to Send (RTS) Pin 9: Not assigned 15.11.2 Specifications for the USB-A Interface Communication: USB host (master) Connectable devices: Sartorius printers, USB memory sticks, USB barcode scanners, USB keyboards 15.11.3 Specifications for the USB-B Interface Communication: USB device (slave) Type of interface: Virtual serial interface (virtual COM-port, VCP) and “PC direct”...

  • Page 85: Accessories

    YWLAN01MS independent Wi-Fi network, e .g ., operation with a Sartorius network printer YDP30-NET (only for Europe) Wireless nano router, e .g ., for Sartorius network YWLAN02MS printer YDP30-NET for operation in an independent Wi-Fi network (only for Europe) Display cable, 3 m, for separate installation of display...

  • Page 86: Hardware And Software For Pipette Calibration

    Accessories 16.1.3 Hardware and Software for Pipette Calibration Item Quantity Order number Pipette calibration kit (hardware) for microbalance VF988 weighing modules 6 .6S and 3 .6P, consists of moisture trap and all required adapters 16.1.4 Titanium Holder Item Quantity Order number Titanium holder For coronary stents up to 38 mm YSH10...

  • Page 87: Sartorius Service

    Sartorius Service 17 Sartorius Service Sartorius Service is available for queries regarding the device . For information about the service addresses, services provided, or to contact a local representative, please visit the Sartorius website (www .sartorius .com) . When contacting Sartorius Service with questions about the system or in the event of malfunctions, be sure to have the device information, e .g .
  • Page 88 Conformity Documents Cubis ® MCA Operating Instructions...

  • Page 89: Certificate Of Compliance

    Project: Date Issued: 70185847 2018-09-24 Issued to: Sartorius Lab Instruments GmbH & Co. KG Otto-Brenner-Strasse 20 Goettingen, Niedersachsen 37079 GERMANY The products listed below are eligible to bear the CSA Mark shown with adjacent indicators 'C' and 'US' for Canada and US or with adjacent indicator 'US' for US only or without either indicator for Canada only.
  • Page 90 Conformity Documents Certificate: 70185847 Master Contract: 167555 Project: 70185847 Date Issued: 2018-09-24 APPLICABLE REQUIREMENTS CSA Standards: CAN/CSA-C22.2 No. 61010-1-12 Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use, Part 1: General Requirements UL Standards: UL Std. No. 61010-1 (3 Edition) - Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use - Part 1: General Requirements...

  • Page 91: Fcc Supplier's Declaration Of Conformity

    Connections between the device and peripherals must be made using shielded cables in order to maintain compliance with FCC radio frequency emission limits. Any modifications made to this device that are not approved by Sartorius may void the authority granted to the user by the FCC to operate this equipment.
  • Page 92 Sartorius Lab Instruments GmbH & Co. KG Otto-Brenner-Strasse 20 37079 Goettingen, Germany Phone: +49.551.308.0 www.sartorius.com The information and figures contained in these instructions correspond to the version date specified below. Sartorius reserves the right to make changes to the technology, features, specifications and design of the equipment without notice.
