Operation and Safety Manual
Original Instructions - Keep this manual with the machine at all times.
Models
400SC
460SJC
PVC 2001
MOL70
ANSI
31215018
®
February 7, 2020 - Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 400SC and is the answer not in the manual?

Questions and answers

Related Manuals for JLG 400SC

Summary of Contents for JLG 400SC

  • Page 1 Operation and Safety Manual Original Instructions - Keep this manual with the machine at all times. Models 400SC 460SJC PVC 2001 MOL70 ANSI 31215018 ® February 7, 2020 - Rev B...
  • Page 2 @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
  • Page 3 WARNING Operating, servicing and maintaining this vehicle or equipment can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle or equipment in a well-ventilated area and wear gloves or wash your hands frequently when servicing.
  • Page 4 The purpose of this manual is to provide owners, users, operators, lessors, and lessees with the precautions and operating procedures essential for the safe and proper machine operation for its intended purpose. Due to continuous product improvements, JLG Industries, Inc. reserves the right to make specification changes without prior notification. Contact JLG Industries, Inc. for updated information.
  • Page 5 FOREWORD SAFETY ALERT SYMBOLS AND SAFETY SIGNAL WORDS This is the Safety Alert Symbol. It is used to alert you to the potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death INDICATES A POTENTIALLY HAZARDOUS SITUATION.
  • Page 6 Modifications Product Safety JLG INDUSTRIES, INC. SENDS SAFETY RELATED BULLETINS TO THE OWNER OF RECORD OF THIS MACHINE. CONTACT JLG INDUSTRIES, INC. TO ENSURE THAT THE Contact: CURRENT OWNER RECORDS ARE UPDATED AND ACCURATE. Product Safety and Reliability Department JLG Industries, Inc.
  • Page 7 FOREWORD REVISION LOG Original Issue A - September 9, 2019 Revision B - February 7, 2020 31215018...

  • Page 8: Table Of Contents

    TABLE OF CONTENTS SECTION - 1 - SAFETY PRECAUTIONS WALK-AROUND INSPECTION ......2-7 Function Check........2-10 GENERAL .
  • Page 9 TABLE OF CONTENTS Maintenance Standstill Cleaning Initiation LIFTING AND TIE DOWN......4-29 Methods .
  • Page 10 TABLE OF CONTENTS - DEUTZ D2011 ........7-13 Preparation and Inspection .
  • Page 11 Hydraulic Oil Operation Chart - Sheet 1 of 2..7-11 3-1. Ground Control Console - 400SC with MSSO ..3-3 7-4. Hydraulic Oil Operation Chart - Sheet 2 of 2..7-12 3-1.
  • Page 12 Standstill Cleaning: DPF Filled with Soot ... . .4-14 Decal Legend - 400SC Turntable .....4-33 Decal Legend - 460SJC Turntable .

  • Page 13: Section 1. Safety Precautions

    This section contains the responsibilities of the owner, user, oper- ator, lessor, and lessee concerning safety, training, inspection, maintenance, application, and operation. If there are any ques- tions with regard to safety, training, inspection, maintenance, application, and operation, please contact JLG Industries, Inc. (“JLG”). 31215018...

  • Page 14: Workplace Inspection

    • All operating personnel must have a thorough understanding the machine in hazardous environments unless approved for of the intended purpose and function of the MEWP controls, that purpose by JLG. including platform, ground, and emergency descent controls. • Ensure that the ground conditions are adequate to support •...

  • Page 15: Machine Inspection

    • Check the machine for modifications to original components. opposite direction. Always return switch to neutral and stop Ensure that any modifications have been approved by JLG. before moving the switch to the next function. Operate con- trols with slow and even pressure.

  • Page 16: Trip And Fall Hazards

    • Hydraulic cylinders are subject to thermal expansion and contraction. This may result in changes to the platform approved by JLG. position while the machine is stationary. Factors affecting • When two or more persons are in the platform, the operator thermal movement can include the length of time the shall be responsible for all machine operations.

  • Page 17: Electrocution Hazards

    SECTION 1 - SAFETY PRECAUTIONS Electrocution Hazards • Enter and exit only through gate area. Use extreme caution when entering or leaving platform. Ensure that the platform • This machine is not insulated and does not provide protection assembly is fully lowered. Face the platform when entering or from contact or proximity to electrical current.

  • Page 18: Minimum Approach Distances (M.a.d.)

    SECTION 1 - SAFETY PRECAUTIONS Table 1-1. Minimum Approach Distances (M.A.D.) Voltage Range MINIMUM APPROACH DISTANCE (Phase to Phase) in Feet (Meters) 0 to 50 KV 10 (3) Over 50KV to 200 KV 15 (5) Over 200 KV to 350 KV 20 (6) Over 350 KV to 500 KV 25 (8)

  • Page 19: Tipping Hazards

    SECTION 1 - SAFETY PRECAUTIONS Tipping Hazards • The minimum approach distance may be reduced if insulating barriers are installed to prevent contact, and the barriers are • Ensure that the ground conditions are adequate to support rated for the voltage of the line being guarded. These barriers the maximum load indicated on the load decals located on the shall not be part of (or attached to) the machine.
  • Page 20 Keep all loads within the confines of the plat- weather events, the time required to lower the platform, and form, unless authorized by JLG. methods to monitor current and potential wind conditions. • Keep the chassis of the machine a minimum of 2 ft. (0.6m) •...

  • Page 21: Beaufort Scale (For Reference Only)

    SECTION 1 - SAFETY PRECAUTIONS DO NOT OPERATE THE MACHINE WHEN WIND CONDITIONS EXCEED SPECIFICATIONS SHOWN IN SECTION 7.2 OR AS SHOWN ON THE CAPACITY PLACARD ON THE PLATFORM BILLBOARD. Table 1-2. Beaufort Scale (For Reference Only) Wind Speed Beaufort Description Land Conditions Number...

  • Page 22: Crushing And Collision Hazards

    SECTION 1 - SAFETY PRECAUTIONS Crushing and Collision Hazards • Keep non-operating personnel at least 6 ft. (1.8m) away from machine during all operations. • Approved head gear must be worn by all operating and • Under all travel conditions, the operator must limit travel ground personnel.

  • Page 23: Towing, Lifting, And Hauling

    SECTION 1 - SAFETY PRECAUTIONS TOWING, LIFTING, AND HAULING MAINTENANCE • Never allow personnel in platform while towing, lifting, or This sub-section contains general safety precautions which must hauling. be observed during maintenance of this machine. Additional pre- cautions to be observed during machine maintenance are •...

  • Page 24: Battery Hazards

    • Use only replacement parts or components that are approved • Always disconnect batteries when servicing electrical compo- by JLG. To be considered approved, replacement parts or com- nents or when performing welding on the machine. ponents must be identical or equivalent to original parts or components.

  • Page 25: Section 2 - User Responsibilities, Machine Preparation, And Inspection

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION SECTION 2. USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION 2.1 PERSONNEL TRAINING The safest means to operate the machine where overhead obstructions, other moving equipment, and obstacles, The Mobile Elevating Work Platform (MEWP) is a personnel depressions, holes, and drop-offs exist.

  • Page 26: Operator Responsibility

    NOTE: Responsibilities for familiarization may vary by region. The following table covers machine inspections and maintenance required by JLG Industries, Inc. Consult local Only properly trained personnel who have received unit-specific regulations for further requirements for MEWPs. The frequency of familiarization shall operate a MEWP.

  • Page 27: Inspection And Maintenance Table

    NOTE: Inspection forms are available from JLG. Use the Service and Maintenance Manual to perform inspections. IMPORTANT JLG INDUSTRIES, INC. RECOGNIZES A FACTORY TRAINED SERVICE TECHNICIAN AS A PERSON WHO HAS SUCCESSFULLY COMPLETED THE JLG SERVICE TRAINING SCHOOL FOR THE SPECIFIC JLG PRODUCT MODEL.

  • Page 28: Basic Nomenclature

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION BASIC NOMENCLATURE 1. Platform 2. Platform Control Console 3. SkyGuard 4. Fly Boom Section 5. Base Boom Section 6. Final Drive Hub 7. Track 8. Chassis and Roller Assembly 9. Turntable 10.

  • Page 29: Pre-Start Inspection

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION Pre-Start Inspection Operation and Safety Manuals – Make sure a copy of the Operation and Safety Manual, AEM Safety Manual (ANSI The Pre-Start Inspection should include each of the following: markets only), and ANSI Manual of Responsibilities (ANSI markets only) is enclosed in the weather resistant storage Cleanliness –...
  • Page 30 SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION Function Check – Once the Walk-Around Inspection is complete, perform a functional check of all systems in an area free of overhead and ground level obstructions. Refer to Section 4 for more specific operating instructions. Platform Gate - Keep gate and surrounding area clean and unobstructed.

  • Page 31: Walk-Around Inspection

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION WALK-AROUND INSPECTION 31215018...
  • Page 32 SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION General Platform Control Console - Switches and levers return to neutral when activated and released, decals/placards secure Begin the Walk-Around Inspection at Item 1, as noted on the and legible, control markings legible. diagram.
  • Page 33 SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION Hydraulic Reservoir - See Inspection Note. Fuel Tank - See Inspection Note. Counterweight - See Inspection Note. Hydraulic Pumps - See Inspection Note. 31215018...

  • Page 34: Function Check

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION Function Check With the platform in the stowed position: a. Drive the machine on a grade, not to exceed the rated Perform the Function Check as follows: gradeability, and stop to ensure the brakes hold. From the ground control console with no load in the plat- b.

  • Page 35: Skyguard Function Test

    SECTION 2 - USER RESPONSIBILITIES, MACHINE PREPARATION, AND INSPECTION SkyGuard Function Test Disengage the SkyGuard sensor, release controls, then recy- cle the footswitch. Ensure normal operation is available. NOTE: Refer to Section 4.6 for additional information on SkyGuard NOTE: On machines equipped with SkyLine, reattach magnetic end of operation.

  • Page 36: Section 3 - Machine Controls And Indicators

    SECTION 3 - MACHINE CONTROLS AND INDICATORS SECTION 3. MACHINE CONTROLS AND INDICATORS GENERAL CONTROLS AND INDICATORS NOTE: The indicator panels use different shaped symbols to alert the operator to different types of operational situations that could THE MANUFACTURER HAS NO DIRECT CONTROL OVER MACHINE APPLICATION AND arise.

  • Page 37: Ground Control Console - 400Sc Without Msso

    3. Engine Start/Auxiliary Power 4. Platform/Ground Select 5. Platform Level 6. Platform Rotate 7. Not Used 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 1001191933 O AC 03500 Figure 3-1. Ground Control Console - 400SC without MSSO 31215018...

  • Page 38: Ground Control Console - 400Sc With Msso

    5. Platform Level 6. Platform Rotate 7. Not Used 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 12. Machine Safety System Override (MSSO) 1001191933 O AC 03490 Figure 3-1. Ground Control Console - 400SC with MSSO 31215018...

  • Page 39: Ground Control Console - 400Sc With Msso And Dpf

    7. Not Used 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 12. Machine Safety System Override (MSSO) 13. Diesel Particulate Filter (DPF) O AC 03520 Figure 3-1. Ground Control Console - 400SC with MSSO and DPF 31215018...

  • Page 40: Ground Control Console - 460Sjc Without Msso

    SECTION 3 - MACHINE CONTROLS AND INDICATORS 1. Indicator Panel 2. Display Gauge 3. Engine Start/Auxiliary Power 4. Platform/Ground Select 5. Platform Level 6. Platform Rotate 7. Jib Lift 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 1001215596 A OAC03510 Figure 3-1.

  • Page 41: Ground Control Console - 460Sjc With Msso

    SECTION 3 - MACHINE CONTROLS AND INDICATORS 1. Indicator Panel 2. Display Gauge 3. Engine Start/Auxiliary Power 4. Platform/Ground Select 5. Platform Level 6. Platform Rotate 7. Jib Lift 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 12.

  • Page 42: Ground Control Console - 460Sjc With Msso And Dpf

    SECTION 3 - MACHINE CONTROLS AND INDICATORS 1. Indicator Panel 2. Display Gauge 3. Engine Start/Auxiliary Power 4. Platform/Ground Select 5. Platform Level 6. Platform Rotate 7. Jib Lift 8. Telescope 9. Power/Emergency Stop 10. Main Boom Lift 11. Swing 12.

  • Page 43: Ground Control Console

    SECTION 3 - MACHINE CONTROLS AND INDICATORS GROUND CONTROL CONSOLE NOTE: On machines with diesel engines, when Glow Plug Indicator is lighted (yellow), wait until light goes out before cranking engine. Engine Start/ Auxiliary Power TO AVOID SERIOUS INJURY, DO NOT OPERATE MACHINE IF ANY CONTROL LEVERS OR To start engine, switch must be held Up until TOGGLE SWITCHES CONTROLLING PLATFORM MOVEMENT DO NOT RETURN TO THE the engine starts.
  • Page 44 SECTION 3 - MACHINE CONTROLS AND INDICATORS Jib Lift (If Equipped) ONLY USE THE PLATFORM LEVELING OVERRIDE FUNCTION FOR SLIGHT LEVELING OF Provides raising and lowering of the jib. THE PLATFORM. INCORRECT USE COULD CAUSE THE LOAD/OCCUPANTS TO SHIFT OR FALL.
  • Page 45 SECTION 3 - MACHINE CONTROLS AND INDICATORS Machine Safety System Override (MSSO) (If Equipped) ALWAYS POSITION EMERGENCY STOP SWITCH TO THE OFF POSITION (PUSHED IN) WHEN MACHINE IS NOT IN USE. Provides emergency override of function controls that are locked out in the event of Power/Emergency Stop Switch Load Sense System activation.
  • Page 46 SECTION 3 - MACHINE CONTROLS AND INDICATORS GROUND CONTROL INDICATOR PANEL 1. Battery Charge 4. Platform Capacity 7. Fuel Level 9. Engine Error 2. System Distress 5. Generator 8. Platform Overload 10. Emissions Temperature 3. Drive Steer Disable 6. Glow Plug 31215018 3-11...

  • Page 47: Ground Control Indicator Panel

    Generator System Distress Indicator Indicates the generator is in operation. The indicator illuminates when the JLG Control System has detected an abnormal condition and a Diagnostic Trouble Code has been set in the system memory. Refer to the Service Manual for...
  • Page 48 SECTION 3 - MACHINE CONTROLS AND INDICATORS Fuel Level Indicator Engine Error Indicator Indicates the level of the fuel in the fuel tank. Indicates an engine fault requiring service or is requesting a cleaning sequence. ½ Emissions Temperature Indicator Indicator illuminates when exhaust Platform Overload Indicator temperature reaches 1022°...

  • Page 49: Ground Control Console Display Gauge

    Ground Control Console Display Gauge The Display Gauge shows engine hours, fuel level (if applicable), and Diagnostic Trouble Codes (DTCs) from both the JLG Control System and the engine control system. During machine start up, with no active DTCs in the control sys- tem, the splash screen displays for 3 seconds and then switches to the main screen.

  • Page 50: Diagnostic Screen

    SECTION 3 - MACHINE CONTROLS AND INDICATORS The Diagnostic Screen displays active and inactive faults from the The Engine Diagnostics Screen displays the SPN (Suspect Param- JLG Control System. An asterisk (*) indicates active faults. eter Number), FMI (Failure Mode Identifier), and Occurrence Count Information.

  • Page 51: Ground Control Console Display Gauge

    SECTION 3 - MACHINE CONTROLS AND INDICATORS INDICATOR LAMP ENGINE HOURS FUEL LEVEL NAVIGATE BACK ARROW NAVIGATE FORWARD ARROW NAVIGATION BUTTONS Figure 3-4. Ground Control Console Display Gauge 3-16 31215018...

  • Page 52: Platform Control Console

    SECTION 3 - MACHINE CONTROLS AND INDICATORS PLATFORM CONTROL CONSOLE 1702676-B 1705170 A 1702938 O AC 02000 1. Drive Speed / Torque Select 5. Start/Auxiliary Power 9. Telescope 13. Soft Touch/SkyGuard Indicator/SkySense Mute 2. Platform Level Override 6. Drive Orientation Override 10.

  • Page 53: Platform Console

    SECTION 3 - MACHINE CONTROLS AND INDICATORS Platform Console Horn A push-type HORN switch supplies electrical power to an audible warning device when pressed. TO AVOID SERIOUS INJURY, DO NOT OPERATE MACHINE IF ANY CONTROL LEVERS OR Power/Emergency Stop Switch TOGGLE SWITCHES CONTROLLING PLATFORM MOVEMENT DO NOT RETURN TO THE OFF OR NEUTRAL POSITION WHEN RELEASED.
  • Page 54 SECTION 3 - MACHINE CONTROLS AND INDICATORS Drive Orientation Override Drive/Steer When the boom is swung over the rear chas- Proportional dual axis joystick is provided sis or further in either direction, the Drive Ori- to control drive and steer. entation indicator will illuminate when the drive function is selected.
  • Page 55 SECTION 3 - MACHINE CONTROLS AND INDICATORS NOTE: Both drive and steer functions work in the opposite direction Soft Touch/SkyGuard/SkySense Override Switch when the boom is positioned over front of the chassis (over idler wheels). For machines equipped with SkyGuard: The SkyGuard override switch enables NOTE: When boom is positioned above horizontal and any of the fol-...
  • Page 56 SECTION 3 - MACHINE CONTROLS AND INDICATORS Soft Touch/SkyGuard Indicator/SkySense Mute Switch NOTE: To operate the Main Boom Lift/Swing joystick, pull up on the locking ring below the handle. Indicates Soft Touch bumper is against an object or the Sky- Guard sensor has been activated.

  • Page 57: Platform Control Indicator Panel

    SECTION 3 - MACHINE CONTROLS AND INDICATORS PLATFORM CONTROL INDICATOR PANEL 1. System Distress 5. Generator 8. Glow Plug 11. Platform Overload 2. Drive Orientation 6. Creep Speed 9. Fuel Level 12. Engine Error 3. Platform Capacity 7. Foot switch Enable 10.
  • Page 58 If the boom is above horizontal and the machine is on a slope, the tilt alarm warning light will illumi- The indicator illuminates when the JLG Control nate, an alarm will sound, available functions are placed in System has detected an abnormal condition Creep speed, and drive is cut out in the direction of travel.
  • Page 59 SECTION 3 - MACHINE CONTROLS AND INDICATORS Creep Speed Indicator Fuel Level Indicator When the Function Speed Control is turned to Indicates the level of the fuel in the fuel tank. the creep position, the indicator acts as a ½ reminder that all functions are set to the slowest speed.
  • Page 60 @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...

  • Page 61: Section 4 - Machine Operation

    The machine has a Ground Control Station that can override the Platform Control Station. Machine is as originally equipped from JLG. Ground controls operate all functions except Drive and Steer. Except for performing inspections and the Function Check, the...

  • Page 62: Platform Load Sensing System (Lss)

    SECTION 4 - MACHINE OPERATION Platform Load Sensing System (LSS) Stability The Platform Load Sensing System provides the platform capac- Machine stability is based on two (2) conditions which are called FORWARD and BACKWARD stability. The machine’s position of ity to the control system. least FORWARD stability is shown in Figure 4-1., and its position If the LSS system senses an overload condition, boom functions of least BACKWARD stability is shown in Figure 4-2.

  • Page 63: Position Of Least Forward Stability

    SECTION 4 - MACHINE OPERATION BOOM FULLY EXTENDED AND HORIZONTAL (0°) MACHINE WILL TIP OVER IN THIS DIRECTION IF OVERLOADED OR OPERATED BEYOND THE LIMITS OF THE MAXIMUM OPERATING SLOPE. O AC 01870 Figure 4-1. Position of Least Forward Stability 31215018...

  • Page 64: Position Of Least Backward Stability

    SECTION 4 - MACHINE OPERATION MACHINE WILL TIP OVER IN THIS DIRECTION PLATFORM ROTATED IF OVERLOADED OR OPERATED BEYOND THE 90 DEGREES LIMITS OF THE MAXIMUM OPERATING SLOPE. MAIN BOOM FULLY ELEVATED AND FULLY RETRACTED O AC 01880 Figure 4-2. Position of Least Backward Stability 31215018...

  • Page 65: Engine Operation

    MANUAL. coolant temperature may occur. NOTE: Diesel engines only: After turning on ignition, NOTE: Contact JLG Customer Service for operation under abnormal operator must wait until glow plug indicator light conditions. goes out before cranking engine. NOTE: Initial starting should always be per-...

  • Page 66: Shutdown Procedure

    SECTION 4 - MACHINE OPERATION Push Engine Start switch until engine starts. Push Engine Start switch until engine starts. NOTE: Footswitch must be in released (up) position before starter will ALLOW ENGINE TO WARM-UP FOR A FEW MINUTES AT LOW SPEED BEFORE APPLYING operate.

  • Page 67: Fuel Reserve / Shut-Off System

    The Fuel Shutoff System monitors the fuel in the tank and senses more fuel available. when the fuel level is getting low. The JLG Control System auto- matically shuts the engine down before the fuel tank is emptied unless the machine is set up for Engine Restart.

  • Page 68: Diesel Particulate Filter (If Equipped)

    SECTION 4 - MACHINE OPERATION DIESEL PARTICULATE FILTER (IF EQUIPPED) Standstill Cleaning The following conditions must be met to perform Standstill Diesel Particulate Filter (DPF) is an emissions control system used Cleaning. in diesel engines and requires operator interaction to make sure proper operation of the system.
  • Page 69 SECTION 4 - MACHINE OPERATION Launch the cleaning process by pressing the DPF button on the Ground Console for 3 seconds. The Indicator Gauge will display the following screen. The Main Cleaning process will begin and last for approxi- mately 30 to 60 minutes. The following screen will show that the process has begun and includes a status bar that indi- cates the progress of the cleaning process.

  • Page 70: Methods

    SECTION 4 - MACHINE OPERATION Canceling Maintenance Standstill After the cleaning process is complete, the engine will run for approximately 5 minutes to allow the Engine and Maintenance Standstill Cleaning will be stopped immediately if: Exhaust After Treatment (EAT) to cool down. The Indicator Gauge will display the "Regen Complete"...

  • Page 71: Unsuccessful Cleaning Event

    SECTION 4 - MACHINE OPERATION Unsuccessful Cleaning Event DPF Filter Replacement due to Ash Load If there is an unsuccessful cleaning event, the DPF icon will show The DPF collects non-burnable particulates which cannot be on the display gauge. Possible causes of an Unsuccessful Clean- removed by the Standstill Cleaning process.

  • Page 72: Ash Load Dpf Filter Replacement

    SECTION 4 - MACHINE OPERATION Table 4-1. Ash Load DPF Filter Replacement DPF Filter Engine Error Ash Load Derate Exchange Indicator Indicator Normal Operation <100% None Filter Exchange Required ≥100% None DPF Filter E xchange Blinking Warning Level ≥105% None DPF Filter E xchange Blinking Continuous...
  • Page 73 Cleaning Indicator* 0-500 Between 500 and 650 hours, Normal None cleaning cycle can be initiated Operation 500-650 with JLG analyzer. Blinking Standstill 650-750 None Engine coolant temperature Required must be >40° C and machine must be in ground station Continuous...

  • Page 74: Standstill Cleaning: Dpf Filled With Soot

    Indicator Indicator* Normal Opera- <99% None tion Will remain in Stand- Blinking 100% to 109% Switch in JLG Machine Standstill still mode for 100 hours None Required or until the soot load 100 Hours JLG Analyzer reaches 109% Will remain in Warning...

  • Page 75: Grade And Side Slopes

    SECTION 4 - MACHINE OPERATION GRADE SI DE SLOPE LEVEL Figure 4-3. Grade and Side Slopes 31215018 4-15...

  • Page 76: Traveling (Driving)

    SECTION 4 - MACHINE OPERATION TRAVELING (DRIVING) DO NOT DRIVE WITH BOOM ABOVE HORIZONTAL EXCEPT ON A SMOOTH, FIRM SUR- See Figure 4-3., Grade and Side Slopes FACE WITHIN THE LIMITS OF THE MAXIMUM OPERATING SLOPE. NOTE: Refer to the Operating Specifications table for Gradeability and TO AVOID LOSS OF TRAVEL CONTROL OR TIP OVER, DO NOT DRIVE MACHINE ON Sideslope ratings.

  • Page 77: Machine Motion Hazard

    SECTION 4 - MACHINE OPERATION Machine Motion Hazard USE EXTREME CAUTION WHEN DRIVING IN REVERSE AND AT ALL TIMES WHEN DRIVING WITH THE PLATFORM ELEVATED. DO NOT USE DRIVE TO MANEUVER PLATFORM CLOSE TO AN OBSTRUCTION. USE ONE OF THE BOOM FUNCTIONS. BEFORE DRIVING, MAKE SURE THE BOOM IS POSITIONED OVER THE REAR OF THE CHASSIS (OVER FINAL DRIVES AND SPROCKETS).

  • Page 78: Traveling Forward And Reverse

    SECTION 4 - MACHINE OPERATION Traveling Forward and Reverse To obtain sharp turns, move Drive Speed/Torque Select switch to the At Platform Controls, with the engine running, back position, slow down the travel pull out Emergency Stop switch and activate speed and move the Drive control footswitch.
  • Page 79 SECTION 4 - MACHINE OPERATION To obtain maximum travel speed, position the Drive control- This machine is equipped with a Drive Orientation Indicator. The yellow light on the platform control console indicates the boom ler to Fast and activate the following switches: is swung beyond the rear and machine may Drive/Steer in the a.

  • Page 80: Drive Function Operating Range Diagrams

    SECTION 4 - MACHINE OPERATION 50 ft. 15.24 m CHASSIS 40 ft. LEVEL 12.19 m 30 ft. 9.14 m REDUCED NOTE: In Transport Mode, High Drive will be disabled above 5° DRIVE SPEED 20 ft. elevation or past 0.5 m (1.6 ft) of boom extension. 6.10 m 10 ft.

  • Page 81: Drive Function Operating Range Diagrams

    SECTION 4 - MACHINE OPERATION 50 ft. 15.24 m CHASSIS TILTED 40 ft. > 1.8° 12.19 m REDUCED DRIVE SPEED 30 ft. 9.14 m 20 ft. 6.10 m NOTE: In Transport Mode, High Drive will be disabled above 10 ft. DRIVE PERFORMANCE PER 5°...

  • Page 82: Traveling On A Grade

    SECTION 4 - MACHINE OPERATION Traveling on a Grade PLATFORM Platform Level Adjustment When traveling on a grade, maximum braking and traction are obtained with the boom stowed, in position over the rear (drive) axle, and in line with the direction of travel. Drive the machine for- ward when climbing a grade, and in reverse when descending a grade.

  • Page 83: Boom

    SECTION 4 - MACHINE OPERATION BOOM TO AVOID A COLLISION AND INJURY IF PLATFORM DOES NOT STOP WHEN A CONTROL SWITCH OR LEVER IS RELEASED, REMOVE FOOT FROM FOOTSWITCH OR USE EMER- GENCY STOP SWITCH TO STOP THE MACHINE. A RED TILT WARNING LIGHT IS LOCATED ON THE CONTROL CONSOLE WHICH LIGHTS WHEN THE CHASSIS IS ON AN EXCESSIVE SLOPE.

  • Page 84: Telescoping The Main Boom

    SECTION 4 - MACHINE OPERATION Telescoping the Main Boom MACHINE SAFETY SYSTEM OVERRIDE (MSSO) (IF EQUIPPED) To extend or retract the main boom, use the Main The Machine Safety System Override (MSSO) is Telescope Control Switch to select In or Out move- used to override function controls for Emergency ment.

  • Page 85: Skyguard

    SECTION 4 - MACHINE OPERATION SkyGuard Reattach magnetic end of cable to bracket if it becomes discon- Approximately 50 lb (222 Nm) of force is applied to yellow bar. nected. SkyGuard - SkyLine SkyGuard - SkyEye Cable is pressed, breaking the magnetic connection between the Operator passes through path of sensor beam.

  • Page 86: Skyguard Function Table

    SECTION 4 - MACHINE OPERATION SkyGuard Function Table Boom Drive Drive Boom Boom Boom Basket Basket Steer Swing Lift Jib Lift Forward Reverse Lift Up Tele Out Tele In Level Rotate Down R = Indicates Reversal is Activated C = Indicates Cutout is Activated 4-26 31215018...

  • Page 87: Shut Down And Park

    SECTION 4 - MACHINE OPERATION SHUT DOWN AND PARK Shut Down and Park The procedures to shut down and park the machine are as fol- lows: Drive machine to a reasonably well protected area. NOTE: When parking on frozen ground overnight, drive machine up on boards to prevent freezing to ground.

  • Page 88: Lifting And Tie Down Chart

    SECTION 4 - MACHINE OPERATION MODELS 400SC 74.4" (189 cm) 42.1" (107 cm) 460SJC 75.19" (191 cm) 41.35" (105 cm) 1001190876 F 1001217209 B Figure 4-8. Lifting and Tie Down Chart 4-28 31215018...

  • Page 89: Lifting And Tie Down

    SECTION 4 - MACHINE OPERATION LIFTING AND TIE DOWN Tie Down (See Figure 4-8.) Lifting WHEN TRANSPORTING THE MACHINE IN THE STOWED POSITION, THE BOOM MUST BE FULLY LOWERED INTO THE BOOM REST. Refer to Serial Number Plate, Specifications section of this manual, or weigh the individual unit to determine Gross NOTE: Putting the platform in certain positions for transporting may...
  • Page 90 SECTION 4 - MACHINE OPERATION OAC01170 Figure 4-9. Decal Location - Turntable - Sheet 1 of 3 4-30 31215018...
  • Page 91 SECTION 4 - MACHINE OPERATION OAC001190 Figure 4-10. Decal Location - Turntable - Sheet 2 of 3 31215018 4-31...
  • Page 92 SECTION 4 - MACHINE OPERATION OAC01240 Figure 4-11. Decal Location - Turntable - Sheet 3 of 3 4-32 31215018...

  • Page 93: Decal Legend - 400Sc Turntable

    SECTION 4 - MACHINE OPERATION Table 4-4. Decal Legend - 400SC Turntable ANSI Korean Eng/Japan Item 1001239558-A 1001239335-A 1001239567-A 1001250835-A 1001239585-A 1703797 1703924 1703927 1705921 1703926 1703798 1703930 1703933 1705822 1703932 1703805 1703936 1703939 1705961 1703938 1703804 1703948 1703951 1701518...
  • Page 94 SECTION 4 - MACHINE OPERATION Table 4-4. Decal Legend - 400SC Turntable ANSI Korean Eng/Japan Item 1001239558-A 1001239335-A 1001239567-A 1001250835-A 1001239585-A 4420051 4420051 4420051 4420051 4420051 1704174 1704174 1704174 1704174 / 1704175 1704174 1001190876 1001190876 1001190876 1001190876 1001190876 1704412 1704412...

  • Page 95: Decal Legend - 460Sjc Turntable

    SECTION 4 - MACHINE OPERATION Table 4-5. Decal Legend - 460SJC Turntable ANSI Korean Eng/Japan Item 1001239561-A 1001239336-A 1001239582-B 1001250836-A 1001239594-B 1703797 1703924 1703927 1705921 1703926 1703798 1703930 1703933 1705822 1703932 1703805 1703936 1703939 1705961 1703938 1703804 1703948 1703951 1701518 1703950 1001217208 1001217208...
  • Page 96 SECTION 4 - MACHINE OPERATION Table 4-5. Decal Legend - 460SJC Turntable ANSI Korean Eng/Japan Item 1001239561-A 1001239336-A 1001239582-B 1001250836-A 1001239594-B 1704174 1704174 1704174 1704174 / 1704175 1704174 1001217209 1001217209 1001217209 1001217209 1001217209 1704412 1704412 1704412 1704412 1704412 1704885 1704885 1704885 1704885 1703953...
  • Page 97 SECTION 4 - MACHINE OPERATION 30 - 400SC 31 - 460SJC OAC01280 Figure 4-12. Decal Location - Chassis 31215018 4-37...

  • Page 98: Decal Legend - 400Sc & 460Sjc Chassis

    SECTION 4 - MACHINE OPERATION Table 4-6. Decal Legend - 400SC & 460SJC Chassis ANSI Korean Eng/Japan Item 1001227662-A 1001227695-A 1001227698-A 1001191076-E 1001215290-C 1701499 1701499 1701499 1701499 1701499 1701529 1701529 1701529 1701529 1701529 1702300 1702300 1702300 1702300 1702300 1702631 1702631...

  • Page 99: Section 5 - Emergency Procedures

    JLG Industries, Inc. must be notified immediately of any incident LIFT ABOVE 3 M (10 FT) UNTIL YOU ARE SURE ALL DAMAGE HAS BEEN REPAIRED, IF involving a JLG product. Even if no injury or property damage is REQUIRED, AND ALL CONTROLS ARE OPERATING CORRECTLY.

  • Page 100: Platform Or Boom Caught Overhead

    If the MSSO functionality is used, the fault indicator is set with a From the ground controls, use the Auxiliary Power System (if fault code in the JLG Control System which must be reset by a equipped) to carefully free the platform or boom from the qualified JLG Service Technician.

  • Page 101: Section 6 - Accessories

    SECTION 6 - ACCESSORIES SECTION 6. ACCESSORIES Table 6-1. Available Accessories Market Accessory ANSI (USA Only) ANSI Pipe Racks     SkyGlazier™     SkyPower™     SkyWelder™     Soft Touch ...

  • Page 102: Options/Accessories Relationship Table

    SECTION 6 - ACCESSORIES Table 6-2. Options/Accessories Relationship Table COMPATIBLE WITH ACCESSORY REQUIRED ITEM INCOMPATIBLE WITH INTERCHANGABLE WITH (Note 2) (Note 1) Pipe Racks SkyPower™ Soft Touch, SkySense SkyGlazier™, SkyWelder™ SkyGlazier™ SkyPower™ Pipe Racks, Soft Touch, SkySense SkyWelder™ Pipe Racks, SkyGlazier™, SkyPower™...

  • Page 103: Fall Arrest Platform

    FALL ARREST PLATFORM PIPE RACKS NOTE: See the JLG External Fall Arrest System manual (PN 3128935) for- more detailed information. The external fall arrest system is designed to provide a lanyard attach point while allowing the operator to access areas outside the platform.

  • Page 104: Safety Precautions

    SECTION 6 - ACCESSORIES Safety Precautions Preparation and Inspection • Ensure racks are secured to the platform rails. • Replace torn or frayed tie-down straps. REDUCE PLATFORM CAPACITY BY 100 LB (45.5 KG) WHEN INSTALLED. Operation To prepare racks for loading, remove locking pins, rotate WEIGHT IN RACKS PLUS WEIGHT IN PLATFORM MUST NOT EXCEED RATED CAPACITY.

  • Page 105: Skyglazier

    SECTION 6 - ACCESSORIES SKYGLAZIER™ Capacity Specifications Max. Platform Capacity Capacity Zone * Max. Tray Capacity (With Max. Weight in Tray) 500 lb 150 lb 250 lb (227 kg) (68 kg) (113 kg) 550 lb 150 lb 250 lb (250 kg) (68 kg) (113 kg) 600 lb...

  • Page 106: Safety Precautions

    SECTION 6 - ACCESSORIES Safety Precautions Preparation and Inspection • Check for cracked welds and damage to tray. • Ensure tray is properly secured to platform. ENSURE PANEL IS SECURED WITH STRAP. • Ensure strap is not torn or frayed. Operation DO NOT OVERLOAD TRAY OR PLATFORM.

  • Page 107: Skypower

    SECTION 6 - ACCESSORIES SKYPOWER™ All power regulation components are located in a watertight box connected by cable to the generator. The generator supplies power when running at the specified speed with the power switch on (switch is located on platform). A three-pole, 30 Amp circuit breaker protects the generator from overload.

  • Page 108: Safety Precautions

    SECTION 6 - ACCESSORIES Safety Precautions DO NOT OVERLOAD PLATFORM. • Ensure no personnel are beneath platform. • This factory-installed option is available only on specified models. • Keep lanyard attached at all times. • Do not use electrical tools in water. •...

  • Page 109: Skywelder

    SECTION 6 - ACCESSORIES SKYWELDER™ Generator Output Engine Speed of 1800 rpm +/- 10%. ANSI Specifications: • 3-phase: 240 V, 60 Hz, 7.5 kW • 1-phase: 240 V/120 V, 60 Hz, 6 kW CE Specifications: • 3-phase: 400 V, 50 Hz, 7.5 kW •...

  • Page 110: Accessory Ratings

    SECTION 6 - ACCESSORIES Accessory Ratings Welding Amps Input At Rated Load Output (50/60 Hz) Maximum Open Welding Mode Input Power Rated Output Amperage Circuit Voltage 230 V 460 V 575 V Range 280 Amp at 31.2 V, 15.7 35% Duty Cycle 3- phase 5-250 A 79 VDC...

  • Page 111: Preparation And Inspection

    SECTION 6 - ACCESSORIES SOFT TOUCH • Use correct rod size and current settings. • Do not use electrical cords without ground. A padding kit is mounted to the platform rails and to a frame sus- • Do not use electrical tools in water. pended below the platform.

  • Page 112: Skysense

    SECTION 6 - ACCESSORIES SKYSENSE™ Preparation and Inspection Pre-Operation Inspection: Inspect each of the SkySense tubes for dents, cracks, or other SKYSENSE IS NOT INTENDED TO REPLACE OR REDUCE THE NEED FOR THE OPERATOR damage. TO BE AWARE OF THE ENVIRONMENT AROUND THE MACHINE. HAZARDS THAT WILL Inspect each SkySense sensor for any damage to the hous- CAUSE SERIOUS INJURY OR DEATH MAY NOT BE PREVENTED OR REDUCED BY SKY- SENSE.

  • Page 113: Operation

    SECTION 6 - ACCESSORIES Recycle the footswitch and press the override button on the SkySense is active during the following functions: platform control console. • Boom Lift Up/Down Continue to lower the platform. The machine should move • Platform Rotate in the elevated drive speed mode (SkySense Status LED will •...

  • Page 114: Skysense Alarm

    SECTION 6 - ACCESSORIES SkySense Alarm Activation of SkySense is signaled by an audible alarm which indicates SkySense activity when reaching the warning or stop zones. In the warning zone, the audible alarm will pulse and increase in frequency as the machine moves closer to the object. In the stop zone, the alarm will sound a continuous tone.

  • Page 115: Override Button

    SECTION 6 - ACCESSORIES Override Button SkySense Coverage Areas The yellow override button allows operators to bypass normal SkySense operation in order to move closer to an object in the stop zone. When the operator overrides the SkySense via the override but- ton to get closer to a work surface, the machine will maintain ele- vated speed and flash the appropriate indicator color based on location in either the warning or stop zones.
  • Page 116 SECTION 6 - ACCESSORIES Level 2 (3 - Bar) NOTE: Sensor Cones shown are approximations for reference only. 6-16 31215018...

  • Page 117: Section 7 - General Specifications & Operator Maintenance

    SECTION 7. GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE INTRODUCTION OPERATING SPECIFICATIONS This section of the manual provides additional necessary infor- Table 7-1. Operating Specifications - 400SC mation to the operator for proper operation and maintenance of this machine. Maximum Work Load (Capacity):...

  • Page 118: Operating Specifications - 460Sjc

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Table 7-1. Operating Specifications - 400SC Table 7-2. Operating Specifications - 460SJC Ground Bearing Pressure: 3661 kg/m (5.21 psi) Maximum Work Load (Capacity): 272 kg (600 lb) Travel Speed 2.57 km/h (1.6 mph) Maximum Operating Slope 5°...

  • Page 119: Capacities

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Engine Data Table 7-2. Operating Specifications - 460SJC Rubber Track GVW: 8,184 kg (17,998) NOTE: RPM Tolerances are ± 100. Maximum Rubber Track Load 5769 kg (12,718 lb) Table 7-4. Deutz D2011L03 Maximum System Voltage Engine Type Four-stroke Diesel...

  • Page 120: Deutz 2.9L4

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Table 7-5. Deutz 2.9L4 Engine Type Four-stroke Diesel Fuel Diesel No. of Cylinders Bore 92 mm Stroke 110 mm Displacement 2925 cm³ (178 cu. in) Oil Capacity 8.9 L (9.5 qt.) Coolant Capacity 11.3 L (12 qt.) Low RPM 1200...

  • Page 121: Hydraulic Oil

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Hydraulic Oil Aside from JLG recommendations, it is not advisable to mix oils of different brands or types, as they may not contain the same required Table 7-6. Hydraulic Oil additives or be of comparable viscosities. If use of hydraulic oil other...

  • Page 122: Mobil Dte 13M Specs

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Table 7-8. Mobil DTE 13M Specs Table 7-9. UCon Hydrolube HP-50/46 ISO Viscosity Grade Type Synthetic Biodegradable Specific Gravity 0.877 Specific Gravity 1.082 Pour Point, Max -40°C (-40°F) Pour Point, Max -50°C (-58°F) Flash Point, Min.

  • Page 123: Mobil Eal 224H Specs

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Table 7-11. Mobil EAL H 46 Specs Table 7-10. Mobil EAL 224H Specs Type Synthetic Biodegradable Type Synthetic Biodegradable ISO Viscosity Grade 32/46 ISO Viscosity Grade Specific Gravity .922 Specific Gravity .910 Pour Point, Max -32°C (-25°F) Pour Point...

  • Page 124: Critical Stability Weights

    40° C 25.8 c St Counterweight (460SJC) - Turntable 1225 2,700 at 100° C 9.3 cSt Counterweight (400SC) - Chassis (Front) 1,200 Viscosity Index Counterweight (400SC)- Chassis (Rear) 1,210 NOTE: Mobil/Exxon recommends to check this oil on a yearly...

  • Page 125: Serial Number Location

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Serial Number Location A serial number plate is affixed to the left side of the frame. If the serial number plate is damaged or missing, the machine serial num- ber is stamped on the left side of the frame. Figure 7-1.
  • Page 126 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Figure 7-2. Engine Operating Temperature Specifications - Deutz 7-10 31215018...

  • Page 127: Hydraulic Oil

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Figure 7-3. Hydraulic Oil Operation Chart - Sheet 1 of 2 31215018 7-11...
  • Page 128 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Fluid Properties Base Classifications Mobilfluid 424 Mobil DTE 10 Excel 32 Univis HVI 26 Mobil EAL Hydraulic Oil Mobil EAL Envirosyn H46 Quintolubric 888-46 * Readily biodegradable classification indicates one of the following: CO2 Conversion >...

  • Page 129: Operation Maintenance And Lubrication Diagram

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE OPERATION MAINTENANCE AND LUBRICATION DIAGRAM - DEUTZ D2011 31215018 7-13...

  • Page 130: Operator Maintenance And Lubrication Diagram - Deutz 2.9L47-14

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE OPERATOR MAINTENANCE AND LUBRICATION DIAGRAM - DEUTZ 2.9L4 7-14 31215018...

  • Page 131: Operator Maintenance

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE OPERATOR MAINTENANCE NOTE: It is recommended as a good practice to replace all filters at the same time. NOTE: The following numbers correspond to those in Figure 7.3, Final Drive Hub Operation Maintenance and Lubrication Diagram - Deutz D2011.
  • Page 132 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Hydraulic Return Filter Hydraulic Tank Breather Interval - Change after first 50 hours and every 6 months or Interval - Change after first 50 hours and every 6 months or 300 hours thereafter or whenever Charge Filter is replaced 300 hours thereafter.
  • Page 133 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Hydraulic Tank Hydraulic Charge Filter Lube Point(s) - Fill Cap Interval - Change after first 50 hours and every 6 months or Capacity - 32.5 gal tank (123 L) 40.0 gal system (151 L) 300 hours thereafter or as indicated by Condition Indicator Lube - HO Interval - Check Level daily;...
  • Page 134 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Oil Change w/Filter - Deutz D2011 Fuel Filter - Deutz D2011 Lube Point(s) - Replaceable Element Lube Point(s) - Fill Cap/Spin-on Element Interval - Every year or 500 hours of operation Capacity - 10 qt (9.5 L) w/Filter Lube - EO Interval - Check level daily;...
  • Page 135 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Oil Change w/Filter - Deutz 2.9L4 Fuel Pre-Filter - Deutz D2.9 Lube Point(s) - Replaceable Element Lube Point(s) - Fill Cap/Spin-on Element Interval - Drain water daily; Every year or 500 hours of Capacity - 9.5 qt (8.9 L) w/Filter operation Lube - EO...
  • Page 136 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Radiator Coolant Deutz 2.9 Fuel Filter - Deutz 2.9L4 Lube Point(s) - Replaceable Element Lube Point(s) - Fill Cap Interval - Every year or 500 hours of operation Capacity - 2.9 Gallon (11.3 L) Lube - Anti-Freeze Interval - Check level daily;...
  • Page 137 SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE Air Filter Swing Bearing - Internal Ball Bearing Lube Point(s) - 2 Grease Fittings Capacity - A/R Lube - MPG Interval - Every 3 months or 150 hours of operation Comments - Fittings in center of bearing: Remote Access is optional: Apply grease and rotate in 90 degree intervals until bearing is completely lubricated Lube Point(s) - Replaceable Element...

  • Page 138: Supplemental Information

    SECTION 7 - GENERAL SPECIFICATIONS & OPERATOR MAINTENANCE SUPPLEMENTAL INFORMATION Swing Drive Hub The following information is provided in accordance with the requirements of the European Machinery Directive 2006/42/EC and is only applicable to CE machines. For electric powered machines, the equivalent continuous A- Weighted sound pressure level at the work platform is less than 70dB(A) For combustion engine powered machines, guaranteed Sound...
  • Page 139 @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...

This manual is also suitable for:

460sjc

Table of Contents
