Technogym RUN NOW EXCITE + Technical Service Manual page 51

RUN NOW Excite +: Technical Service guide - rev. 6.2
iPod
interface
board
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CU519: FLAT iPod interface cable (UNITY)
ANALOGUE SIGNAL
(iPod Interface Board / iPod board)
signal
Remote sense
Remote sense
Video CVBS
A/V return
n.c.
A/V return
A/V return
AUDIO LEFT
A/V return
AUDIO RIGHT
A/V return
GND_ Shield
GND_ Shield
Colour iPod board
Brown
1
White
2
White 3
Shield 4
- 5
6
7
8
Green 9
Yellow 10
White
11
Shield
12
White 13
Shield 14
Black 15
Pink 16
Page 2.39
