RUN NOW Excite +: Technical Service guide - rev. 6.2
2.10.3. TRM
CABLES
ARM Board
CN1
1
...
14
ALE/AT UL
driver
J8
3
8
Boards
CPU: CN16/17
ARM: CN11/13
1 Reference
2 Grade -
Reference
3
4 Grade +
TRM-31: C-Safe Signal cable (LED only)
(ARM Board – C-Safe Board)
Signal
Digital #1
...
Digital #14
TRM-54: Limit Switch cable
(ALE/AT UL Driver – Limit Switch)
Signal
Contact
Reference
TRM-29: Up-Down and Speed Joystick cable
(CPU / ARM Board– Joystick)
Signal
-
+
Colour
Flat cable
...
Flat cable
Colour
White
Brown
Micro Joystick
Colour
Up
White -
Brown -
Green Faston (C)
Yellow Faston (NA)
C-Safe Board
CN1
1
...
14
Limit Switch
Fast-on
Fast-on
Down
Faston (C)
Faston (NA)
-
-
Page 2.29
