KINTEX UltraScale+ FPGA Board AXKU042 User Manual
QSPI Flash pin assignments:
Signal Name
QSPI_CCLK
QSPI0_CS_B
QSPI0_IO0
QSPI0_IO1
QSPI0_IO2
QSPI0_IO3
Signal Name
QSPI_CCLK
QSPI1_CS_B
QSPI1_IO0
QSPI1_IO1
QSPI1_IO2
QSPI1_IO3
15 / 56
Figure 4-2: QSPI Flash Schematic
FPGA Pin Name
RDWR_FCS_B_0
D00_MOSI_0
FPGA Pin Name
CCLK_0
IO_L2N_T0L_N3_FWE_FCS2_B_65
IO_L22P_T3U_N6_DBC_AD0P_D04_6
IO_L22N_T3U_N7_DBC_AD0N_D05_65
IO_L21P_T3L_N4_AD8P_D06_65
IO_L21N_T3L_N5_AD8N_D07_65
Amazon Store: https://www.amazon.com/alinx
CCLK_0
D01_DIN_0
D02_0
D03_0
5
FPGA Pin Number
AA9
U7
AC7
AB7
AA7
Y7
FPGA Pin Number
AA9
G26
M20
L20
R21
R22
