Chore-Time ATF PLUS Installation And Operator's Manual page 11

Feeding system
Hide thumbs Also See for ATF PLUS:
Table of Contents

Advertisement

Figure 3. For Systems over 350' (107 m)
Key
Description
1
Full Line Suspension Kit
2
1' (30 cm) maximum
3
Swivel Pulley
4
3.5" (8.9 cm) Pulley
5
Power Winch
6
Key #7 + 2' (61 cm)
7
Maximum Distance of Travel
8
Double Clamp Here
9
3' (90 cm) Maximum
10 Drop Line
11 Single Clamp Here
