FMS 1:24 FCX24 UNIMOG Instruction Manual page 7

Product Introduction
产品参数
Specification
● Length:249mm
● Width:153mm
● Height:160mm
● Wheelbase:142mm
● Tire F/R :Φ 59*20mm
● Minimum Ground Clearance: 40mm
● Approach Angle: 49°
● Departure Angle: 69 °
● 车长: 249mm
● 车宽: 153mm
● 车高: 160mm
● 轴距: 142mm
● 轮胎: Φ 59*20mm
● 离地间隙: 40mm
● 接近角: 49°
● 离去角: 69 °
产品信息
40mm
142mm
249mm
● Motor: 130 Brushed motor
● Battery : 2S Lipo 7.4V 380mAh x1
● Remote control distance: 30m
● Approx. operating duration time: 20mins
● Remote control: G3+ R3A transmitter, receiver with
● 电机：130有刷电机
● 电池：2S Lipo 7.4V 380mAh
● 遥控距离：30m
● 续航：20mins
● 遥控：G3 + R3A 发射器，接收机/电调(二合一)
ESC group control board
7
90mm
153mm
160mm
