Product Introduction

The two-speed mechanical transmission is operated by a 9g steering gear that can be switched using the third channel
on the remote control. The low gear reduction ratio is 99, which is larger than that of similar products currently on the
market. The torque output is strong, and easy for extreme climbing. The high gear reduction ratio is 24.75, and the
speed is higher than that of all similar products currently on the market. In addition to enjoying the charm of mechanical
shifting, the two-speed transmission enables more ways to enjoy your driving experience.
At present, a variety of upgraded and modified parts such as metal link rods, metal differential, metal universal joint
drive shaft, metal gears, brass wheel counterweights, etc. have been launched to match the FCX24 chassis. In
addition to further improving the performance of the vehicle, these parts also provide a variety of personalized options.
Unimog dominates all kinds of complex terrain. As always, you can trust FMS.
由戴姆勒-奔驰汽车公司授权，FMS模型出品的这款遥控仿真模型车1/24 乌尼莫克421（Unimog 421)在外观仿真度方面仍旧保持一
贯的高水准。这款模型的设定是典型的特种运输形态，可以胜任复杂道路条件下的运输工作。车头标志性的进气格栅刻画极其精细。车上
装有加宽的后视镜和涉水器，车顶有两个橘黄色的警示灯，透过车窗可以看到精美的仪表盘和座舱内饰。引擎盖可以打开，方便更换电池
，同时这里也是遥控系统电子板的收纳空间。此外，后货斗三面均可打开，方便装卸货物。实车货斗地板和三面门板都是木制的，我们在
这里雕刻了精细的纹理模拟实木的质感。
乌尼莫克采用FCX24系列高性能攀爬底盘（在底盘上增加油箱、电瓶等像真组件），车架采用高强度尼龙一体成型，相比金属侧梁加
塑胶桁架拼接的梯形大梁，整体重量更轻，强度更高。中置动力总成重心低，将2档变速机构、分动箱和130电机整合为一体。动力通过万
向节传动轴传输到前后两个车桥，车桥装有轮边减速器，俗称"门桥"，可以加大差速器的离地间隙，提高通过性。
攀爬车一般搭配前后直轴，模拟真车差速器锁止状态，以提高越野通过能力。FCX24默认搭载直轴，但也可以更换为行星齿差速器，
搭配高粘度硅油，模拟LSD限滑差速器的行驶效果。安装差速器后极限攀爬能力将会降低，但可以获得更小的转向半径，更稳定的高速行
驶品质。简单的说直轴适合极限攀爬，限滑差速器适合高速越野，任君选择。
两档变速箱使用遥控器第三通道，通过一颗9G舵机操作，低速档减速比99，大于目前市面上的同类产品，低扭输出强劲，极限攀爬
游刃有余。高速档减速比24.75，车速大于目前市面上所有同类产品，除了机械变速的魅力外，还可以组合多种玩法，在各种地形条件下体
会不同的操控乐趣。
目前配合FCX24底盘已经有金属拉杆、金属差速器、金属万向节传动轴、金属齿轮、黄铜轮毂配重等多款升级改装零件上市。这些零
件除了进一步提升车辆性能外，还提供多种个性化的选择。
产品特点
Features
● DAIMLER-BENZ AG LICENSED PRODUCT
● READY TO RUN MODEL
● TWO-SPEED TRANSMISSION
● ABS HARD BODY
● REMOTE CONTROL LIGHTING SYSTEM
● PORTAL AXLE (METAL GEAR)
● METAL GEARS STEERING SERVO
● FOUR LINK SUSPENSION
● HIGH STRENGTH INTEGRATED NYLON
FRAME
● 戴姆勒-奔驰汽车公司授权产品
● RTR组装完成品
● 微型两档机械变速
● 仿真硬塑料车壳
● 遥控灯光系统
● 门式车桥（金属齿轮）
● 金属齿转向舵机
● 4连杆悬挂
产品信息
● FUNCTIONAL HOOD
● RESTORED INTERIOR FEATURES
● PAINTED BODY, THREE COLORS AVAILABLE
● OPTIONAL MODIFICATION PARTS,LIKE METAL
LINK RODS, METAL DIFFERENTIAL, METAL
UNIVERSAL JOINT DRIVE SHAFT, METAL
GEARS, BRASS WHEEL COUNTERWEIGHTS,
ETC. AVAILABLE
● 高强度混纤尼龙一体成型车架
● 活动式功能引擎盖
● 像真驾驶艙内饰
● 喷涂完成车壳,三款涂装可选
● 金属拉杆、金属差速器、金属万向节传动轴、金属齿
轮、黄铜轮毂配重等多款升级改装件可选
