FMS 1:24 FCX24 UNIMOG Instruction Manual page 10

Getting Started
Transmitter Antenna
The transmitter has a built-in antenna. When the transmitter starts to work, the antenna automatically operate, without
additional operations.
本发射机天线为内置天线，发射机开始工作，天线自动工作，无需单独进行操作 !
Receiver and Servo Installation
Make sure that the receiver is mounted in an appropriate location within the model, to ensure a stable signal,
Pay attention to the following when installing the receiver:
1. Make sure the receiver is not installed near ESCs or other sources of electrical noise.
2. Keep the receivers antenna away from conductive materials such as carbon or metal. To ensure normal function
make sure there is a gap of at least 1cm between the antenna and the conductive material.
请结合相应模型的结构选择合适的位置安装接收机， 同时为了确保接收机的性能和遥控距离的稳定，并防止外界干扰，
安装过程中请注意以下事项：
1.确保接收机安装在远离电机，电子调速器或电子噪声过多的区域。
2.接收机天线需远离导电材料 , 例如金属棒和碳纤物质。为了避免影响正常工作，请确保接收机和导电材料之间至少有 1厘米以上的距离。
Caution To prevent damage do not power on the receiver during installation.
小心
准备过程中，请勿连接接收机电源，避免造成不必要的损失。
Installing Transmitter Battery
Danger Only use specified battery (X4 AAA batteries).
危险
仅使用厂家指定的电池。
Danger Do not open, disassemble, or attempt to repair the battery.
请勿打开、拆卸或自行维修电池。
危险
Danger Do not crush/puncture the battery, or short the external contacts.
危险 请勿挤压、刺穿或接触电池的金属端子。
Danger Do not expose to excessive heat or liquids.
危险
请勿将电池置于高温环境或液体中。
Danger Do not drop the battery or expose to strong shocks or vibrations.
危险
请注意防止电池跌落、碰撞或振动。
Danger Always store the battery in a cool, dry place.
危险
请将电池存放在干燥阴凉的环境中。
Danger Do not use the battery if damaged.
危险
如果电池损坏，请立即停止使用。
Battery Type: AAA
Follow the steps below to install the batteries:
1. Open the battery compartment cover.
2. Insert 4 AAA batteries with the correct polarity. Make sure it is connected with the correct polarity to avoid damage.
3. Replace battery compartment cover.
Low battery alarm: When the battery is lower than 4.2V, the transmitter will give a alarm with the LED flashing slowly.
使用前准备
发射机天线
接收机与舵机安装
发射机电池安装
10
