The control panel must necessarily be installed as it
is essential for generator operation.
Do not use devices different from the control provided
with the generator, since they may be
incompatible with the generator.
Make the connection with the battery detached.
The control panel is supplied with a 10 m long
connection cable.
Do not modify this cable as it may cause im proper
functioning of the panel circuit.
3.7.3 A.C.

CONNECTION

This connection can be made by means of the power
terminal board.
Generator earthing.
High voltage may cause serious injury or death.
Electroconduction is possible whenever electricity is
present.
De-energise the main magnetothermal switches
of all the power outputs before repairing the equipment.
Configure the installation for earthing of the generator
and the electrical circuits when in use.
Avoid contact with the electrical conductors or equipment
when standing in water or on wet ground, since there is
a higher risk of electroconduction in these conditions.
Short-circuits. High voltage may cause serious
injury or death.
Short-circuits may cause physical injury and/or damage
to the equipment. Avoid contact with the electrical
connectors through tools or jewellery. Take off wrist
watches, rings or any other jewellery before working on
the electrical circuits.
GB
- 28
L1
L1 L0 GRD
N
120V
230V
60 Hz 50Hz
N
