1.6 R
EFERENCE DOCUMENTS
The instructions for use provided with each generator
are made up of a collection of documents of which this
manual represents the General Part. The following
documents are normally provided separate.
a CE declaration of conformity.
b Instruction manual for use and maintenance of
the generators,(this manual).
c Engine use and maintenance manual.
d List of Service Centres.
e Warranty certificate.
f Warranty card.
g EPA certificate (Engine manufacturing)
1.7 R
EFERENCE REGULATIONS AND LEGISLATIVE PROVISIONS
The generator groups, destined to the countries of the
European Community, are conforming to the applicable
EC directives, andthey are providedof a EC Declaration
of Conformity.
EN 12601: Reciprocating internal combustion engine
driven generating sets.
98/37/EC and subsequent amendments:
Essential machine requirements for safety and health
protection ("Machine" directive).
73/23/EC and subsequent amendments contained in
the directive 93/68/EC : Guarantee of safety of electrical
material intended for use within certain voltage limits,
("LowVoltage" Directives).
EN 60204.1: Electrical equipment of machines.
1.8 M
ARKING
The generator identification plate carries all the
identification data conforming to ISO 8528 and in
accordance with the provisions for EC marking for
those cases where required. Below is a facsimile of the
identification plate fixed on the hull of each generator.
1.9 I
DENTIFICATION OF THE GENERATOR UNIT
1 - Machine name
2 - Machine code
3 - Serial number
4 - Rated power
5 - Declared frequency
6 - Rated power factor
7 - Rated voltage
8 - Rated current
9 - Degree of protection
10 - Class of isolation
11 - Temperature max. of use
12 - Altitude max. of use
13 - Performance class
14 - Year of construction
15 - Manufacturer - Adress
16 - Weight
1
2 Code
4
Rated power 3F
5
declared frequency
6
Rated power factor
7
Rated voltage
Rated current
8
9
Degrees of protection
10
Class of insulation
11
Temp. max of use
12
Altitude max. of use
13
Performance class
14
year of manifacture
The machine code number, the serial number
and the year of construction must always be
indicated when contacting the manufacturer
for information, order of spare parts, etc..
IS 6.1
Serial n°
KVA
Hz
Cos.
Ø
V V
A A
IP
°C
m
Mass Kg
