Wiring Diagram - Directed Directechs DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Brake Switch
(white conn. at brake switch)
1
2 3 4
(+) Brake: Green, pin 1
Refer to Specific
connection for manual
transmission vehicle for
wire and connector
details related to the
standard connections in
the vehicle.
D2D Port
(+) Starter Output
(AC) Tach Output
(-) Ground (-) Ground
(+) Ignition Input/Output
(-) Parking Lights Output
(+) 12V Input
(+)12V: Orange, pin 3
3 2 1
6 5 4
Relay Block
(white conn. right of
OBDII)
6 403.MA1 4.07 2013 Mazda 3 (Smart Key)
© 2020-06-02 Directed. All rights reserved.
Junction connector
(white conn. behind BCM)
(-) SComm:
White,
pin 15
Non SKYACTIV engine
OR
SKYACTIV engine
OR
BCM
(blue conn.
bottom of BCM)
24 12
23 11
22 10
21 9
20 8
C
(-) Parking 19 7 D
Lights:
18 6
Gray, pin 23
17 5
16 4
15 3 (-) Trunk Release:
Brown, pin 8
14 2
13 1
(-) RAP Off:
Blue, pin 4
BCM
12 11 10 9 8 7 6 5
(white conn.
24 23 22 21 19 18 17
20
above driver kick)
Junction connector
(white conn. behind BCM)
(-)SComm:
White,
pin 16
HS CAN High: Tan/Black: 3
Door Trigger Interrupt. (conn. side): Yellow: 8
Door Trigger Interrupt (veh. side): Orange/Yellow: 9
(-) Ground: Yellow/Red:11
(-) Trunk Release Output: Brown/Red: 12
(-) SComm: Black/White: 1
(-) Push-to-Start Output: Green/Black: 2
(AC) Tach Output: Violet/White: 5
Ignition Status Output: Gray/Black: 7
(MUX) Door Lock Output: Violet/Brown: 9
Data TX: Yellow/Black: 10
Data RX: Orange/Black: 11
CUT
4 3 2 1
15 14 13
16
Door Lock/
Factory Alarm (MUX):
Dk. Green, pin 13
HS CAN High: White, pin 6
1 8
9 16
HS CAN Low: Red, pin 14
HS CAN Low: Tan: 4
RX:
Blue, pin 1
1
2
TX:
3
Lt. Blue,
pin 2
4
P.A.T.S Transceiver
(white conn. on key slot)
(-) Push-to-Start: Violet, pin 7
Start/Stop Switch
(white conn. at push button)
).
OBDII
Diagnostic
Connector
XKD2D65
