Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.

Key2GO programming using 1 key

Important! BEFORE proceeding with the programming sequence:
1
Remove any and all blade keys from their Smart Key cards, and make sure Smart Key
cards are located at a minimum of 10 feet (3 meters) away from the vehicle.
Additionally, make sure all doors are closed on the vehicle.
Wait until the LED turns ON solid red.
2
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. Wait until the LED turns ON solid orange, then
proceed with step 3.
Remove the cap covering the key slot (right side of the steering column), and insert the
first key in the slot.
3
If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF when programming is done.
4
Press and release the brake or clutch pedal.
Press the Push-to-Start (PTS) button twice to turn the ignition ON. The LED starts flashing
5
green to indicate the CAN was detected.
6
Press the PTS button once more to turn the ignition OFF.
7
Press and release the brake or clutch pedal.
8
Press the PTS button twice to turn the ignition ON. The LED starts flashing orange.
Press the PTS button once more to turn the ignition OFF, remove the module from the
9
vehicle, and reconnect it to your computer. The web site will automatically recognize
that you are moving onto the second phase of the programming sequence.
10
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid
11
green for 3 seconds, then turns OFF.
You have successfully completed the module programming sequence.
12
403.MA1 4.07 2013 Mazda 3 (Smart Key)
