- Page 1 403.GM9 v2.48 2022 Cadillac XT4 (Smart Key)
-
Page 2: Table Of Contents
Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Wiring diagram Locating components in the vehicle Keyport Location Vehicle connections Module programming Module programming for convenience only (skip transponder) Key2GO SmartStart/XL202 installation notes Connecting the module LED diagnostics and troubleshooting Parking light error codes Soft reset Hard reset... -
Page 3: Introduction
Introduction DB3 is an all-in-one door lock and override module. This guide supports the installation of a DB3 in Remote Start Ready (RSR) mode. This solution may offer up to three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation (if applicable, refer to the “Vehicle function compatibilities” below), RF System or SmartStart (all sold separately). -
Page 4: Vehicle Function Compatibilities
E-Brake Status 3x LOCK START (Start control using OEM Remote) Ignition Status 3x LOCK STOP (Stop control using OEM Remote) OEM Remote Start Activation using XL-202 or RF kit 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 5: Pre-Installation And Application Warnings
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if not supported in data. 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 6: Wiring Diagram
7 pin 4 Remote Start Safety Override Switch Single Wire CAN: 11 12 Green, pin 22 (blue conn. drivers dash, or center console Hood Pin front passenger side) 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 7: Locating Components In The Vehicle
Locating components in the vehicle 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 8: Keyport Location
Open the center console and place the transmitter in the transmitter pocket. Chevrolet Suburban (Smart Key) 2015 - 2020 Open the center console and place the transmitter in the transmitter pocket. 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... - Page 9 Place the transmitter in the front cupholder. GMC Yukon (Smart Key) 2015 - 2020 Open the center console and place the transmitter in the transmitter pocket. Front Cupholder Center Console Front Center Console Cupholder 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights...
-
Page 10: Vehicle Connections
No Connection H2/12 Blue/Red No Connection No Connection Input 10-pin black connector (H3) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color H3/1 Green No Connection No Connection 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... - Page 11 (Data) TX H4/2 Black (-) Ground H4/3 Blue (Data) RX H4/4 (+) 12 Volt RF 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 No Connection H5/2 No Connection 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights...
-
Page 12: Module Programming
When the configuration is completed, reconnect the module. The LED turns ON solid green for three (3) seconds, then turns OFF. You have successfully completed the module programming sequence. 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 13: Module Programming For Convenience Only (Skip Transponder)
The LED flashes orange then turns ON solid orange for 3 seconds then shuts OFF. x 3 sec Press once (1) more on the PTS button to turn the ignition OFF. You have successfully completed the module programming sequence. 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 14: Key2Go
Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application. -
Page 15: Smartstart/Xl202 Installation Notes
SmartStart/XL202 installation notes The DB3 Remote Start Ready (RSR) solution offers three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF Kit or SmartStart (both sold separately). This section provides specific installation information for SmartStart and XL202. -
Page 16: Connecting The Module
Note: Before connecting either the XL202 or SmartStart module to DB3, it is important to ensure that the proper feature and function programming is selected using DirectLink (version 4.5 or higher). Visit www.directechs.com to download the latest version of the application. -
Page 17: Led Diagnostics And Troubleshooting
External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... - Page 18 Lock Start is selected from the web in the flashing process. Flashes red x 7 Feature error. An RSR feature file mismatch was detected. Please contact Technical Support. Flashes red x 9 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights...
-
Page 19: Parking Light Error Codes
Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Release Solid 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 20: Limited One Year Consumer Warranty
This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... -
Page 21: Quick Reference Guide (Customer Copy)
With Get In and Go, you simply remote start the vehicle, unlock the doors, get in and go... All that's left to do is put the gear in drive and drive off. 403.GM9 2.48 2022 Cadillac XT4 (Smart Key) ©2023 Directed. All rights... - Page 22 * Press & hold for 5 seconds to activate the trunk release (optional). * Icon and remote appearance may differ depending on the model purchased. SmartStart compatible This system is compatible with Directed SmartStart. For a complete list of supported features, please visit www.mysmartstart.com. What is SmartStart? Now you can remote start, lock and unlock your car just by pushing a button on your mobile device;...
