Assignment - EDIO
The assignment depends on the unit version (DX1, DX2, CW, EC Tower 2). Explanation see page 7.
If several EDIO boards exist, the EDIO board on the lowest socket is detected as the first EDIO board and the in- and outputs are
assigned correspondingly when using the "loaddefault" command. The IOC board features four sockets for this purpose: X10, X11,
X12 and X13. X10 represents the lowest socket.
Pin Designation
1 Din 12
2 Din 13
3 Din 14
4 Din 15
5 Din 16
6 Din 17
7 Din 18
8 Din 19
9 Dout 8 (NO)
10 Dout 8 (COM)
11 Dout 8 (NC)
12 Dout 9 (NO)
13 Dout 9 (COM)
14 Dout 9 (NC)
15 Dout 10 (NO)
16 Dout 10 (COM)
17 Dout 10 (NC)
18 Dout 11 (NO)
19 Dout 11 (COM)
20 Dout 11 (NC)
21 Dout 12 (NO)
22 Dout 12 (COM)
23 Dout 12 (NC)
24 Dout 13 (NO)
25 Dout 13 (COM)
26 Dout 13 (NC)
27 PWM1
28 GND
29 PWM2
30 GND
X10 SUB-D 15
Pins 31 to 40 are not assigned.
BA C7000 for EC Tower | EN | 01-2019 | 1000755
EC Tower 2
free
free
free
free
free
free
free
free
free
free
free
free
free
free
free
free
free
E-reheat 1 (proportional)
free
