3. Hardware components

3.1 I/O controller (C7000 IOC)

Service port
JP 7
RS232
Green LEDs for red LEDS for
digital inp. 1-11 digital outp. 1-7
6
Dipswitch Plugs for EBUS
for bus adr. exp. board
JP 2 3 4 5
Technical data:
Electrical supply:
Power consumption:
Fuse:
Operating temperature: 5 °C to 40 °C
Storage temperature:
LEDs on the circuit board
The function of the digital inputs is indicated by the
green LEDs:
ON: voltage present
OFF: no voltage (Alarm, error)
The function of the digital outputs is displayed by
the red LEDs:
ON: relay energized
OFF: relay not energized
The OK LED displays the IIC bus clock. The sensors
are evaluated in this cycle.
The TX1/RX1 LEDs display the data traffic on the
I/O bus (port 1).
The Error LED lights up if an alarm has occurred.
Pin position of X1
1 10 21
11 20 31
JP 9 JP 8
Jumper settings according to the
A-IN 1
A-IN 2
4 sockets
A-IN 3
for EDIOs/
EAIOs/
A-IN 4
EEIO
A-IN 5
*Exception: for PT1000/100 on existing
OK LED
systems
TX1 LED
RX1 LED
Error LED
Driver module
for the I/O bus
For further information, see page 12.
EBUS activation
JP 6
Jp n°
8
9
Jp8 and Jp9 have to be set if there is no EBUS
expansion board. On the contrary, they have to be
removed to activate the RS485 expansion buses
on the plugged EBUS expansion board.
BA C7000 for EC Tower | EN | 01-2019 | 1000755
24(+15 %) V (AC)
9.6 VA
2 A inactive
-30 °C to 60 °C
30 41
40 51
sensor type
Jp n° Pos.1-2 Pos.2-3
2
3
4
5
6 not usable*
Jumper for software download
Jp n° Pos. 1-2 Pos. 2-3
7 Operation Download
Function, when set
EBUS port 2 deactivated
EBUS port 3 deactivated
50
60
