Stulz S-Klima C7000 User Manual page 27

Room, supply-air limited
Setpoint
Room air
T/°C
Temperature
T
max
20.5
20
13 14 15
Supply air, room limited
Start value 1 > Start value 2
Setpoint
Supply air
T/°C
Temperature
T
max
18.5
18
17.5
T
min
20 21
BA C7000 for EC Tower | EN | 01-2019 | 1000755
Config
You can set temperature limit values for the room control with supply-air limit and for
the supply air control with room-air limit.
Above/below the limit value, the raised/reduced temperature setpoint stays at the limit
value.
➎
➏
Lower limit value (T
Upper limit value (T
The control diagrams are changed by the adjusted temperature limit values as shown
opposite (room, supply-air limited) or below (supply air, room limited).
16 T/°C
Actual value
Supply air sensor
Actual value
22 23 24 T/°C
Air/Control type (Part 3)
): ➎
min
): ➏
max
Start value 1< Start value 2
Setpoint
Supply air
T/°C
T
max
18.5
18
17.5
T
min
20
Room air
sensor
Values
Temperature
21 22 23 24 T/°C
Actual value
Room air
sensor
27
