Accelnet
DIMENSIONS
AEV-090-50, AEV-090-50-C
.692 17.58
.185 4.7
.800 20.32
AEV-090-14, AEV-090-30, AEV-180-10, AEV-180-20
.692 17.58
.185 4.7
.800 20.32
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
P/N 16-01681 Rev 15
Plus
Micro
2.500 63.5
1.60 40.6
2.320 58.93
Dimensions are in inches [ mm ].
2.500 63.5
2.320 58.93
Module EtherCAT
.948 24.09
.090 2.29
.105 2.67
*
1.044 26.51
* These pins are longer
for soldering to the user
PC board.
.948 24.09
.090 2.29
.105 2.67
.860 21.85
Tel: 781-828-8090
AEV
.897 22.79
.897 22.79
