Accelnet
EZ BOARD I/O CONNECTORS
LOGIC INPUTS
Signal
EZ-Board
IN1 Enable IN1
IN2 IN2
IN3 IN3
IN4 IN4
IN5 IN5
IN6 Encoder Fault IN6
IN7 SLI MISO IN7
SGND SGND
Logic inputs max input voltage is +6 Vdc.
IN5 is connected to P1, the primary encoder Motemp input. If it is
not used for that function then IN5 is available as a logic input.
* Rxx shows the locations of 0 Ω resistors that are in place by
default as R44 and R40.
R44 connects the Encoder Fault signal to IN6.
R40 connects the SLI-MISO signal to IN7 which is used by the SLI
port that controls the LEDs and reads the address switches.
If neither of these functions are needed then R40 and/or R44 can
be removed making
IN6 & IN7 available as logic inputs
LOGIC OUTPUTS
EZ-Board Signal
DOUT1 DOUT1
DOUT2 DOUT2
DOUT3 (Brake) DOUT3
DOUT4 (SLI-MOSI) DOUT4
DOUT5 (SLI-CLK) DOUT5
DOUT6 (SLI-EN1) DOUT6
SGND SGND
OUT3 is connected by default to the MOSFET that is the Brake
output on J10. OUT1~2 are available is logic outputs.
OUT4~6 connect to the SLI circuit that drives the displays and
reads the address switches. If the SLI function is not needed
then these outputs can be used as logic outputs by removing the
Rxx as follows:
OUT4: R41
OUT5: R42
OUT6: R43
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
P/N 16-01681 Rev 15
Plus
J5 Pins
4
3
6
5
8
7
10
15, 17, 18
J5 Pins
12
9
14
11
16
13
15, 17, 18
Micro
Module EtherCAT
AEV EZ J5
*
Rxx 0
[IN1~7]
SGND
[DOUT1~3]
74HCT2G14
[DOUT4~6]
74LVC3G14
Tel: 781-828-8090
AEV J1
+5V +5V
10k
[IN1~7]
1K
100p
SGND
AEV EZ J5
AEV J2
+5 Vdc
[DOUT1~3]
Sgnd
SGND
AEV J2
+3.3 Vdc
[DOUT4~6]
Rxx
0
SGND
SGND
Fax: 781-828-6547
AEV
+3.3V
74LVC3G14
±4 mA
R
±24 mA
R
