PC BOARD MOUNTING & DRILLING DIMENSIONS
4X Ø 0.035 [0.89]
2.320 58.93
2.080 52.83
1.818 46.19
1.751 44.46
64X Ø 0.028 [0.71]
0 0
.090 2.29
For Sockets on User PC Board:
Qty Description
1 Socket Strip
1 Socket Strip
1 Socket Strip
2 Standoff
or Soldering to User PC Board:
F
Qty Description
1 For J1, refer to this document:
2 Standoff
Copley Controls, 20 Dan Road, Canton, MA 02021, USA
P/N 16-01681 Rev 15
Plus
Top view looking down on mounting PC board
1.600 40.64
J3
1 3
2 4
63 64
J2
1 2
Dimensions are in inches [ mm ]
Mfgr Part Number
Samtec SQT-119-01-G-D
Samtec FLE-132-01-G-DV-K-TR
Samtec TLE-102-01-G-DV-TR
hex, 20.5 mm long, M2.5 mm thread
Mfgr Part Number
http://suddendocs.samtec.com/processing/through-hole-printing.pdf
hex, 15 mm long, M 2.5 mm thread
Micro
Module EtherCAT
2X Ø 0.105 [2.67]
37 38
38X Ø 0.035 [0.89]
2.500 63.50
J1
1 2
Notes
1. J1 signals must be connected for current-
2. To determine copper width and thickness for J1
3. Standoffs should be connected to etches on
Ref Des
J1
J2
J3
Ref Des
Tel: 781-828-8090
J1 Signal Grouping
for current-sharing
sharing.
signals refer to specification IPC-2221.
(Association Connecting Electronic Industries,
http://www.ipc.org)
pc board that connect to frame ground for
maximum noise suppression and immunity.
They also provide the PE (Protective Earth)
connection between the heatplate and ground.
Remarks
0.0787 in (2.00 mm) pitch
0.050 in (1.27 mm) pitch
0.0787 in (2.00 mm) pitch
Remarks
Fax: 781-828-6547
AEV
37 38
1 2
