FD-R Basic.3
Programming the effects
Flashing
By assigning the flashing function to 2 outputs
and the "inverted switching" function to one of
the two outputs, an alternating flashing is
generated.
The flashing frequency is set separately for each
output.
Kick function
The outputs first receive full voltage for a
maximum of approx. 25.5 seconds and are then
switched off. The kick time is set separately for all
outputs.
Example of use: Some types of electrical couplings
require full voltage to decouple. However, the
voltage should be switched off after uncoupling in
order to protect the couplings.
Dimming
To reduce the voltage at the output.
Example of use: The lights of older vehicles
intended for analogue operation can be dimmed
and then do not need to be replaced after the
decoder has been installed.
English
CV programming
(CV 58-60, CV 101-104)
CV programming
(CV 58-60, CV 99)
CV programming
(CV 47-50)
