System Layout - quadient IS-420 User Manual

2.1

System Layout

Mailing system with feed-table
Weighing Platform
Automatic Label
Dispenser
System Base
Control Panel
Label Storage
User Guide Receptacle
Catch Tray
Jam Release Handle
Feed Table
Measures the weight of mail pieces.
Contains labels to be printed.
Prints envelopes (or labels) and controls the Mailing
System.
Allows you to control the Mailing System.
Use this slot to store extra labels horizontally.
Receives mail pieces after processing.
Allows you to remove jammed envelopes or labels.
Beginning of the mail transport path.
