Infinity CHECK POINT 1100 Administration Manual page 86

5. Click Apply.
The IP address is added to the table.
6. Change the WEB Port (HTTPS) and/or SSH port if necessary.
7. Click Apply. An administrator can access the Check Point Appliance using the configured IP
addresses through the allowed interface sources.
To allow administrator access from both specified and any IP addresses:
Select this option when it is necessary to allow administrator access from the Internet (you must
define the specified IP addresses). Access from other sources is allowed from any IP address.
1. Select the Internet source checkbox.
2. Select the Specified IP addresses from the internet and any IP address from other sources
option.
3. Click New.
The IP Address Configuration page shows.
4. Select Type:
• IPV4 address
• IPv4 network
•
IPv6 address (1200R and 1400 appliances only)
•
IPv6 network (1200R and 1400 appliances only
5. Enter the IP address or click Get IP from My Computer.
6. Click Apply.
The IP address is added to the table.
7. Change the WEB Port (HTTPS) and/or SSH port if necessary.
8. Click Apply. An administrator can access the Check Point Appliance using the configured IP
addresses through the allowed interface sources.
To delete administrator access from a specific IP address:
1. Select the IP Address you want to delete from the IP Address table.
2. Click Delete.
Important Notes:
• Configuring different access permissions for LAN and Internet is not supported when your
Internet Connection is configured in bridge mode (the option Allow administration access
from does not show Internet or LAN).
•
An automatic implied rule is defined to allow the access specified here. There is no need to add
an explicit rule in the Access Policy page to allow this access.
• When you block the IP address or the interface group through which you are currently
connected, you are not disconnected immediately. The access policy is applied immediately,
but your current session remains active until you log out.
Check Point 1100/1200R/1400 Appliances Centrally Managed Administration Guide R77.20.70
Appliance Configuration
| 86
