Infinity CHECK POINT 1100 Administration Manual page 73

6. Click OK.
7. Click any service and select a service name or enter a service name in the search field. You
can create a new service or service group.
Note - Static routes are not supported for source based or service based routes.
8. Optional - Enter a comment.
9. Enter a Metric between 0 and 100. The default is 0.
10. Click Apply.
To configure a default route:
1. Go to Device > Local Network page.
2. Select an interface and click Edit.
The Edit window opens in the Configuration tab.
3. Click the DHCP Server options tab.
4. In the Default Gateway section,
• Click Use this gateway's IP address as the default gateway.
Or
• Select Use the following IP address and enter an IP address.
5. Click Apply.
To edit a default route:
1. In Device > Internet, click the Internet connection.
2. Click Edit.
The Edit Internet Connection window opens in the Configuration tab.
3. Set the Default gateway (next hop) to a different IP address.
4. Click Apply.
When no default route is active, this message shows: "Note - No default route is configured.
Internet connections might be down or not configured."
For Internet Connection High Availability, the default route changes automatically on failover
(based on the active Internet connection).
When a network interface is disabled, all routes that lead to it show as inactive in the routing
page. A route automatically becomes active when the interface is enabled. Traffic for an inactive
route is routed based on active routing rules (usually to the default route).
The edit, delete, enable, and disable options (on the Device > Local Network page) are only
available for manually defined routing rules created on this page. You cannot edit, delete, enable,
and disable routing rules created by the operating system for directly attached networks or rules
defined by the dynamic routing protocol.
To edit an existing route:
Select the route and click Edit.
To delete an existing route:
Select the route and click Delete.
