Configuring A Hotspot - Infinity CHECK POINT 1100 Administration Manual

X-Windows display manager
•
• Avaya IP phone
Nortel IP phone
•
• Thomson IP phone
Custom Options
Lets you add custom options that are not listed above. For each custom option, you must configure
the name, tag, type, and data fields.

Configuring a Hotspot

In the Device > Hotspot page you can configure:
• Guest access - A session is created for an IP address when a user accepts terms or
authenticates in the Hotspot portal. The session expires after the configured timeout (240
minutes by default).
•
Hotspot portal - Customize the portal's appearance.
• Hotspot exceptions - Define specified IP addresses, IP ranges or networks to exclude from the
Hotspot.
If no network interface was defined for the Hotspot, click Configure in Local Network.
In the Access section of the page, you can configure if authentication is required and allow access
to all users or to a specified user group (Active Directory, RADIUS or local).
Hotspot is automatically activated in the system.
To turn off Hotspot:
1. Go to Device > Advanced Settings.
2. Search for Hotspot and double-click the entry.
3. Select Disabled.
4. Click Apply.
To configure Hotspot for an interface:
1. Click Configure in Local Network.
The Local Network window opens.
2. Select interface and click Edit.
The Edit <interface> window opens.
3. Select Use Hotspot.
4. Click Apply.
Any user that browses from configured interfaces is redirected to the Check Point Hotspot portal.
To configure Hotspot exceptions:
1. Click Manage Exceptions.
The Manage Hotspot Network Objects Exceptions window opens.
2. Select the objects to add as exceptions.
The Selected Network Objects window shows the selected objects. To remove an object from
the list, click the x next to it.
Check Point 1100/1200R/1400 Appliances Centrally Managed Administration Guide R77.20.70
Appliance Configuration
| 70
