The Home Tab
Viewing System Information
The Home > System page shows an overview of the Check Point Appliance.
The Check Point Appliance requires only minimal user input of basic configuration elements, such
as IP addresses, routing information, and blade configuration. The initial configuration of the
Check Point Appliance can be done through a First Time Configuration Wizard. When initial
configuration is completed, every entry that uses http://my.firewall shows the WebUI Home >
System page.
System Information - Shows the appliance model, installed software version, name, MAC
•
address, system date and time (with the GMT setting), and system uptime.
•
Network - Shows Internet information and (where applicable) the wireless network status.
Click the links to configure these options.
•
Security Management - Shows authentication status of the Security Management Server and
security policy data. You can click the link to open the Security Management Server page.
•
Network Activity - Shows live data graphs of packet rate and throughput.
Controlling and Monitoring Software Blades
The Home > Security Dashboard page shows you the active blades.
The software blades are shown in these groups:
Access Policy - Contains the Firewall, Application Control and URL Filtering, User Awareness,
•
and QoS blades.
•
Threat Prevention - Contains the Intrusion Prevention (IPS), Anti-Virus, Anti-Bot, Threat
Emulation, and Anti-Spam blades.
Note - The Threat Emulation Software Blade is only supported in R80.10 management and
higher. This blade is not supported for 1100 appliances.
•
VPN - Contains the Remote Access and Site to Site VPN blades. It also contains certificate
options.
The software blades are enabled through SmartDashboard. For more information, see the
Prevention Administration Guide
To view blade and license information:
Click the information icon.
To view statistics:
1. Click the bar graph icon.
The blade statistics window opens.
2. If the blade is turned on:
•
View the graph and details.
•
To go to other blade statistics, click the arrows in the header.
3. If the blade is turned off or has no license:
Click View demo to see an example of the statistics shown and then click Close.
