4. Enter a name for the Check Point Appliance object and select the hardware type for the
hardware platform.
If the appliance does not appear in the hardware list in the R77.30 SmartDashboard, see
sk111292 http://supportcontent.checkpoint.com/solutions?id=sk111292.
5. Set the Security Gateway Version to R77.20.
6. Select the Static IP address or Dynamic IP address to get the gateway's IP address.
7. Click Next.
To configure a static IP address:
1. In the Authentication section, select Initiate trusted communication securely by using a
one-time password or Initiate trusted communication without authentication (less secure).
2. If you selected Initiate trusted communication securely by using a one-time password, enter
a one-time password and confirm it. This password is only used to establish the initial trust.
Once established, trust is based on security certificates.
Important - This password must be identical to the one-time password you define
for the appliance in the First Time Configuration Wizard.
3. In the Trusted Communication section, select Initiate trusted communication automatically
when the Gateway connects to the Security Management server for the first time or Initiate
trusted communication now.
4. Click Connect.
A status window appears.
5. Click Next.
To configure a dynamic IP address:
1. In the Gateway Identifier section, select one identifier: Gateway name, MAC address or First to
connect.
2. In the Authentication section, select Initiate trusted communication securely by using a
one-time password or Initiate trusted communication without authentication (less secure).
3. If you select Initiate trusted communication securely by using a one-time password, enter a
one-time password and confirm it. This password is only used for establishing the initial trust.
Once established, trust is based on security certificates.
Important - This password must be identical to the one-time password you define
for the appliance in the First Time Configuration Wizard.
4. Click Next.
To configure the software blades:
In the Blade Activation page, select the software blades that you want to activate and configure.
To configure blades later:
1. Select Activate and configure software blades later.
2. Click Next.
