Advanced tab
For PPPoE
•
IP Address Assignment - In Local tunnel IP address, select if the IP address is obtained
automatically or manually configured. If manually configured, enter the IP address.
•
Service Provider Settings - In Service, enter a service name (optional) and select the
Authentication method.
•
Connect on demand - Select the Connect on demand checkbox if necessary. This is relevant
only when you are in high availability mode.
For PPTP and L2TP
•
IP Address Assignment -
•
In Local tunnel IP address, select if the IP address is obtained automatically or manually
configured. If manually configured, enter the IP address.
•
In WAN IP assignment, select if the WAN IP address is obtained automatically or manually
configured. If manually configured, enter the IP address, Subnet mask, and Default
gateway.
•
Service Provider Settings - In Service, enter a service name (optional) and select the
Authentication method.
•
Connect on demand - Select the Connect on demand checkbox if necessary. This is relevant
only when you are in high availability mode.
Port Settings
•
If necessary, select Use custom MTU value and set the MTU size. Note that for a DMZ interface
the MTU value is applied to all LAN ports.
•
MAC address clone - If you select Override default MAC address, you can override the default
MAC address used by the Internet connection. This is useful when the appliance replaces
another device and wants to mimic its MAC address.
•
If necessary, select Disable auto negotiation. This lets you manually define the link speed of
the Internet connection.
•
Select the Link Speed.
QoS Settings (bandwidth control) - supported in IPv4 connections only
To enable QoS bandwidth control for download and upload for this specified connection, select the
applicable Enable QoS (download) and/or Enable QoS (upload) checkboxes. Enter the maximum
Kbps rates for the selected options as provided by your ISP for the Internet upload and download
bandwidth.
Make sure that the QoS blade has been turned on. You can do this from Home > Security
Dashboard > QoS > ON.
Check Point 1100/1200R/1400 Appliances Centrally Managed Administration Guide R77.20.70
Appliance Configuration
|
57
