Appliance Configuration
To capture packets:
If a packet capture file exists, a note shows the date of the file and you can download it before you
start a new packet capture that overwrites the existing file.
1. Select an option from the Select Network list.
2. Click Start and then Stop when you want to stop packet capturing.
3. Click Download File to view or save the capture file.
You can activate packet capture and go to other WebUI application pages while the packet capture
runs in the background. However, the packet capture stops automatically if the WebUI session
ends. Make sure you return to the packet capture page, stop and download the capture result
before you end the WebUI session.
Note - The capture utility uses tcpdump. "fw monitor" is available through the command line
interface.
When the mini-USB is used as a console connector in 700 appliances, Windows does not
automatically detect and download the driver needed for serial communication. You must
manually install the driver. For more information, see sk111713
https://supportcontent.checkpoint.com/solutions?id=sk111713.
To download the Windows driver for Mini-USB console socket (1400 appliances only):
Click the Download link.
Note - This page is available from the Home, Device, and Logs & Monitoring tabs.
