SNMP Traps Receivers
You can add, delete, or edit the properties of SNMP trap receivers.
• To add an SNMP trap receiver, click New.
Note - To add a new SNMP v3 trap receiver, there must be an SNMP v3 user defined for it.
To edit an existing SNMP trap receiver, select the trap receiver from the list and click Edit.
•
• To delete an SNMP trap receiver, select the trap receiver from the list and click Delete.
SNMP Traps
You can enable or disable specified traps from the list and for some traps set a threshold value.
The enabled traps are sent to the receivers.
To edit an SNMP trap:
1. Select the trap from the list and click Edit.
2. Select the Enable trap option to enable the trap or clear it to disable the trap.
3. If the trap contains a value, you can edit the threshold value when necessary.
4. Click Apply.
