To edit the radio settings:
1. Click Radio settings.
2. Select the correct Operation mode, Channel, Channel width, and Transmitter power.
3. Click Advanced to set the Guard Interval and Antenna control.
4. Click Apply.
This configuration is global for all wireless networks. Some options may not be available or
allowed depending on your country's wireless standards.
1100 appliances only: The wireless client search options depend on the frequency that the
appliance is set to. The Check Point Appliance can be configured to only one frequency: 2.4
GHz. The Home > System page shows the wireless radio status.
1430/1450 appliances only: The wireless client search options depend on the frequency that
the appliance is set to. The Check Point Appliance can be configured to only one frequency at a
time and is set to 2.4 GHz by default. If you change the radio settings to 802.11 ac or 802.11
ac/n, the frequency automatically changes to 5 GHz. The Home > System page shows the
wireless radio status.
1470/1490 appliances only: There are two radio transmitters: 2.4 GHz and 5 GHz. Each
network is configured separately under a specified transmitter.
Dynamic Frequency Selection (DFS) detects radar signals that must be protected against
interference from 5.0 GHz (802.11ac/n) radios. When these signals are detected, the operating
frequency of the 5.0 GHz (802.11ac/n) radio switches to one that does not interfere with the radar
systems. DFS is enabled by default.
To edit a wireless network:
Click Edit Settings.
The Edit window opens in the Configuration tab.
Configuration tab
Network name (SSID) - Enter a name for the wireless network or use the default name.
This is the name shown to clients that look for access points in the transmission area.
Use Hotspot - Select this checkbox to redirect users to the Hotspot portal before allowing
access from this interface. Hotspot configuration is defined in the Device > Hotspot page.
Wireless Security
Protected network (recommended) - This is the recommended wireless security setting.
Security type - Select the security technology used in your wireless network. WPA/WPA2 is
the most compatible option. WPA2 is the most secure.
Encryption type - Select the encryption method.
Authenticate using - Select Password or RADIUS server (Enterprise mode) to determine
how the users authenticate.
The Password option allows a single password for all users. This option is known as WPA
Personal.
The RADIUS servers (Enterprise mode) option requires defining RADIUS servers in the
Users & Objects > Authentication Servers page. Each user that tries to connect to the
wireless network is authenticated through the RADIUS server. This option is also known as
WPA Enterprise.
Check Point 1100/1200R/1400 Appliances Centrally Managed Administration Guide R77.20.70
Appliance Configuration
|
59
