Transport Tray Assembly Replacement Guide

7. After rotating the picker, remove the large piece of foam from the picker

mechanism by pulling the foam gently outward (Figure 27).

Figure 27 The robotic picker's large piece of foam.

8. Proceed to Install the Replacement Transport Tray Assembly on page 22.
