1. Fit the power switch bracket around the power switch. Make sure the bracket is properly

aligned.

2. Use the #2 Phillips screwdriver to replace the two screws that hold the power switch

bracket to the chassis (Figure 12).

Page 14

Install the New Back Bay Panel

Figure 15.

Replace the power switch bracket screws.

P.N. 90910883
