Remove the Old Back Bay Panel
1. Use the #2 Phillips screwdriver to remove the two screws holding the power switch bracket
to the chassis (Figure 12).
Figure 12.
Remove the power switch bracket screws.
2. Remove the power switch bracket.
Spectra 12000 270-Pin to 300-Pin Passive QIP Upgrade Guide
Page 11
