Lexmark XM3250 Service Manual page 424

Assembly 18: Staple finisher tamper assembly
Asm-index P/N Units/mach Units/FRU Description
1 40X8754
2 40X8754
3 40X8750
4 40X8754
5 40X8125
6 40X8749
1 1 Sensor (stapler
paddle HP)
1 1 Sensor (stapler left
tamper HP)
2 2 Stapler tamper drive
belt
1 1 Sensor (stapler right
tamper HP)
2 1 Stapler tamper motor
1 1 Tamper sub-assembly
Parts catalog
Removal procedure
"Sensor (stapler paddle HP) removal" on
page 368
"Sensor (stapler left tamper HP)
removal" on page 367
"Tamper drive belt removal" on
page 362
"Sensor (stapler right tamper HP)
removal" on page 366
"Motor (stapler left tamper) removal" on
page 341
tamper) removal" on page 342
"Tamper sub-assembly removal" on
page 360
424
or "Motor (stapler right
7018
