VisuNet RM Shell 6
Profiles Management App
Example 3 – Limited Number of Connection Retries to the Same Host
(via "Retry" Feature)
In this example, the RM / BTC connects automatically to a predefined host A. If the connection
fails or gets lost, the RM / BTC will try to reconnect to host A 3 times. If the connection cannot
be established, the RM / BTC will not connect to host A after the third retry. After the third retry
fails, the user automatically returns to the RM Shell home screen.
Use case: This enables the user to manually select an alternative connection if the main con-
nection to host A failed.
Remote Monitor
Auto
Connect
Retry
Figure 6.14
Setting Up Limited Number of Connection Retries to the Same Host
1.
Go to RM Shell's profile management, choose the profile you want to set up, and click
2.
Use the slider to adjust the time after which VisuNet RM Shell automatically establishes a
connection to the requested profile.
3.
Enable the "Retry" feature.
Figure 6.15
4.
Use the "Retry Count" slider to adjust the number of retries.
5.
Use the slider to adjust the time after which VisuNet RM Shell automatically attempts to
reconnect to the host.
50
Host A
Network
3 x
Example 3 - Limited number of connection retries to the same host
.
Corresponding settings in the VisuNet RM Shell (profile settings - connection features)
