Pepperl+Fuchs VisuNet RM Shell 6 Manual page 45

VisuNet RM Shell 6
Profiles Management App
"Backup Connection" Feature
In case a connection to the host gets lost and cannot be reconnected by the "Retry" feature,
you can set up another profile as a backup.
Setting Up Backup Connection
1.
Go to Profile Settings.
2.
To set up the backup connection feature for a profile, click
The "Connection Features" dialog box opens.
3.
Check the "Enable Backup Connection" box.
Figure 6.8
4.
Choose a backup profile from the list that will be started if the connection of the selected profile
fails.
5.
Use the "Establish Backup after..." slider to adjust the time before the backup profile connects
to the host.
6.
Click "OK."
The backup connection has been set up. The enabled backup connection is now activated.
The green square shows that connection features are enabled within this connection.
.
45
