VisuNet RM Shell 6
Profiles Management App
Example 2 – Connecting Continuously to More Than One Host (via
"Backup Connection" Feature)
In this example, the RM / BTC connects automatically to a predefined host A. If the connection
fails, the RM / BTC will try to connect to the profile's backup connection (in this case, "host B")
after a predefined waiting time. If host B is also not reachable, the RM / BTC will try to connect
to the host B profile's backup connection (in this case, "host C"). You can easily create "loops"
of backup connections for your profiles. In this example, the backup connection of host C is
host A again.
Use case: If you have an infrastructure with redundant servers, you can set up the RMs / BTCs
to connect to a backup server if the main server fails.
Remote Monitor
Auto
Connect
Backup
Connection
Figure 6.11
Setting Up a Continuous Connection to More Than One Host
1.
Go to RM Shell's profile management, choose the profile you want to set up (e.g., "host A"),
and click
2.
Enable "Auto Connect" feature.
3.
Use the slider to adjust the time after which RM Shell automatically establishes a connection to
the requested profile.
4.
Enable the "Backup Connection" feature.
5.
Choose the first backup profile (in this case, "host B").
48
Host A
Connection
failed
Network
Backup Host B
Example 2 - unlimited number of connection retries to more than one host (via "Backup
Connection" feature)
.
Host B
Host C
Connection
Connection
failed
failed
Backup Host C
Backup Host A
