2001 Exploded View.eps
CLASS I APPLICATIONS
15 Cubic Feet Maximum
(Less Pressure Switch)
CSA Approval applies to
WPS Style EXP Pressure Switch Only
Pepperl+Fuchs
"Terms & Conditions of Sale" information is printed on every
order acknowledgement; copies are available upon request.
LPS Style
®
Inc. • Telephone (330) 486-0002 • FAX (330) 425-4607 • E-mail: sales@us.pepperl-fuchs.com • www.bebcoeps.com
We reserve the right to make modifications and no guarantee
of the accuracy of the information contained herein is given.
M
R
E
APID
XCHANGE
I
NSTALLATION
BEBCO EPS
1002
ODEL
T
Y
YPE
®
P
URGING
& O
PERATION
WPS & WPSA Style
(With Pressure Switch)
© 2003 Pepperl+Fuchs
511932, Dwg No. 129-0196 (Supercedes 1002-IOM) Printed in U.S.A.
Z
OR
S
YSTEM
M
ANUAL
®
Inc., Twinsburg, Ohio
Advertisement
Table of Contents
Related Manuals for Pepperl+Fuchs BEBCO EPS 1002
Summary of Contents for Pepperl+Fuchs BEBCO EPS 1002
- Page 1 ® "Terms & Conditions of Sale" information is printed on every We reserve the right to make modifications and no guarantee © 2003 Pepperl+Fuchs Inc., Twinsburg, Ohio order acknowledgement; copies are available upon request. of the accuracy of the information contained herein is given.
-
Page 2: Table Of Contents
NEC - NFPA 70, Article 500, NFPA 496 All specifications are subject to change without notice. and ISA ds12.4. Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 3: Identifying Your System
To assist you through the installation and operation of your pressurization / purge system, Pepperl+Fuchs, Inc. has provided the following information boxes throughout this manual. This information is intended to clarify certain differences between the model styles and configurations and to warn the user / installer of potential dangers of electrical shock or enclosure over pressurization. -
Page 4: General Information
Anodized Cast Alum. Enclosure Warning Nameplate: Silkscreened SS Lexan ® is a registered trademark of the General Electric Company Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 5: Enclosure And Device Design
Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 6: Installation Overview
CONNECTION FITTINGS ENCLOSURE ENCLOSURE WARNING REFERENCE NAMEPLATE TUBING SYSTEM SUPPLY TUBING ELECTRICAL ALARM WIRING CONDUIT & SEAL Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 7: Getting Started
In all cases, the most prevalent gas must determine Connections for Lighter than the location of inlet and outlet connections. Air Gases and Vapors Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 8: System Mounting
Typical Pipe Mounted System Typical Panel/Frame Mounted System (Model 1002-LPS-CI-Z-LH shown) (Model 1002-LPS-CI-Z-LH shown) (Model 1002-LPS-CI-Z-PM shown) Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 9: Hardware Mounting
Enclosure Warning Nameplate - Class II EPV - 2 - SA - 90 Side Mount Enclosure Temperature Warning Nameplate Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 10: Mounting Plate Dimensions
.375" O.D. 15.3125" TYP. 4 TYP. 4 1002-LPS-TM 1002-WPS & WPSA-TM (Top Mount Configuration) (Top Mount Configuration) Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 11: Mounting Plate Dimensions (Cont.)
11" 13" 1002-LPS-FM & 1002-LPS-PM 13" (Frame & Panel Mount Configuration) 1002-WPS & WPSA-FM (Frame Mount Configuration) Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 12: Pneumatic Tubing Requirements
EFC- EBC- ENCLOSURE SUPPLY & REFERENCE FITTINGS PRB-4 SYSTEM ATMOSPHERIC REFERENCE FITTING EPC-12 MULTIPLE ENCLOSURE CONNECTION FITTING Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 13: Tubing Installation
All work must be performed by technicians qualified in pneumatic tubing and electrical conduit installation. Pepperl+Fuchs recommends the use of .035" wall thickness, welded or seamless stainless steel tubing. If flexible tubing is used, it must be installed in a manner which will protect it from damage and corrosion. -
Page 14: Tubing Connection Diagrams
Enclosure Pressure Control Valve System Supply Inlet Bulkhead HELPFUL HINT Pneumatic Connections Regulator are bolded. Protected Enclosure Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 15: Electrical Supply Requirements
Pressurized mentioned NFPA requirement. Raceway Protected Enclosure Or Device Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 16: Conduit Installation
Conduit Tube WPSA Style EXP Pressure Switch Port Fitting With Cover Removed LCK “L” Fitting Conduit Kit Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 17: Set-Up Procedure
(if utilized) and test the function of the time Exchange Cycle for all applications. alarm system. 9. Cease testing and remove test equipment. Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 18: Operating Sequence
Control Valve Model 1002-LPS Front View EXP Pressure Loss Alarm Switch Model 1002-WPS & WPSA Front View Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... -
Page 19: Trouble - Shooting Procedures
This section covers the most common problems documented with these systems. Any problems not covered in this section should be addressed directly to our factory. Please address all service needs to Pepperl+Fuchs, Inc. - Customer Service Department at (330) 486-0002. - Page 20 DELIVERY Pepperl+Fuchs® Inc. will deliver its products F.O.B. from its warehouse, place of manufacture or other place from which the products are actually shipped within the U.S.A. Freight charges will be prepaid and added to invoice.
-
Page 21: System Maintenance
Examine the entire Protection System and the protected enclosure(s), and replace any defective parts during routine shutdown of the protected enclosure(s). Parts are available from Pepperl+Fuchs on immediate notice as required. MAINTENANCE SCHEDULE... -
Page 22: Customer Notes
CUSTOMER NOTES Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... - Page 23 CUSTOMER NOTES Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com...
-
Page 24: Systems Identification & Application Information
Date of Installation Unit Serial # Item Customer P.O.# Customer Project# Service Type Features Application NOTES: Local Sales Representative Pepperl+Fuchs®Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.bebcoeps.com BEBCO EPS Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: sales@us.pepperl-fuchs.com... - Page 25 0-30 psi Body: Zinc w/Enamel Finish Handle: Polycarbonate Hex Key Size: 5/64" Gauge: Steel Case & Brass Tube ® Pepperl+Fuchs Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.am.pepperl-fuchs.com Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: greenteam@us.pepperl-fuchs.com...
- Page 26 The Universal Mounting Plate is an alternative to the Mounting Plates standard LPS style mounting plates listed on the specifi cation bulletins for Pepperl+Fuchs Model 1001A, 1002, 1003, 1004 & 1005 Type Y & Z enclosure protection systems. The Universal Mounting (UM) Plate is furnished as one (1) face plate containing all system components and one (1) universal fl...
-
Page 27: Important Notes
Height & Width dimensions refl ect face plate measurements. Depth dimension refl ects overall depth of all front and rear mounted components. ® Pepperl+Fuchs Inc. • 1600 Enterprise Parkway • Twinsburg, Ohio 44087-2245 • www.am.pepperl-fuchs.com Telephone (330) 486-0002 • FAX (330) 425-4607 • E-Mail: greenteam@us.pepperl-fuchs.com...
