Hardware Installation and Reference Guide
1

Product Overview

1.1

About the RG-RAP6260(H)-D Access Point

The RG-RAP6260(H)-D is a dual-radio access point designed to cover a medium or large outdoor area.
Compliant with the IEEE 802.11a/b/g/n/ac/ax standard, the access point can work at the 2.4 GHz and 5 GHz
bands at the same time and supports quad-stream MU-MIMO. The access point provides a combined data rate
of about 6000 Mbps, with up to 1148 Mbps in the 2.4 GHz band and 4804 Mbps in the 5 GHz band. The access
point provides one 2.5GE electrical port and one 1GE optical port. The electrical port adopts either IEEE 802.3bt
PoE power supply or 48 V DC local power supply.
The enclosure of RG-RAP6260(H)-D meets the IP68 protection grade, which withstands the extreme outdoor
environment and can effectively avoid the influence of bad weather and environment. The mounting method
greatly simplifies the installation and maintenance.
RG-RAP6260(H)-D is PoE-capable and can be applied to a wide variety of outdoor scenarios in the industries
including higher education, government, health care, general education, finance and business.
1.2

Package Contents

Table 1-1 Package Contents
Item
RG-RAP6260(H)-D Access Point
Hose Clamp
Mounting Plate Assembly
M8 x 20 mm Screws
M8 x 60 mm Expansion Anchors
User Manual
Warranty Card
Cable Gland for SFP Port
Cable Gland for Ethernet Port (Pre-installed on the
access point)
SFP Port Plug (Pre-installed on the access point)
Mounting Arm
DC Connector Plug (Pre-installed on the access point)
Cable Gland for DC Connector
Quantity
1
2
1
6
4
1
1
1
1
1
1
1
1
1
