Fiber Recoaters with Linear Proof Testers

Description

3.1.

Introduction

The PTR406 and PTR406B are optical fiber recoaters with have an integrated linear proof tester. The recoat mold
applies a flexible UV acrylate coating to a fusion spliced section of fiber, and the proof test function ensures that a
fiber or fusion splice meets a minimum strength requirement.
3.2.

Parts Checklist

When unpacking the device for the first time, check to make sure that you have the following:
•
PTR406 or PTR406B Manual Fiber Recoater with Linear Proof Tester
•
Plastic Bag, Taped to Unit, Containing
Six 4-40 x 3/16" Fillister-Head Screws
o
Pin with C-Clip
o
•
12V Power Supply
•
AC Line Cord
•
Handset Controller
•
Canvas Zipper Bag Containing:
USB Y- Cable
o
Lens Tissue
o
Eye Dropper
o
Quartz Mold Cleaning Brush
o
3/32" Hex Key
o
0.035" Hex Key
o
Small Bottle with Cap
o
Mold Assembly (Purchased Separately)
o
Top Inserts for Fiber Holding Blocks (Purchased Separately)
o
Bottom Inserts for Fiber Holding Block (Purchased Separately)
o
•
UV-Curable Acrylate Recoat Material (Purchased Separately)
•
For PTR406B Only: Manual Injector
•
If Ordered Separately: Injection Syringes and Cap
If you are missing any of the above or need replacements, please contact Thorlabs.
