Unpacking The Appliance; Removing The Protective Film; Disposing Of Packaging; Positioning - TECNOEKA EKF 664 TC Original Operating And Instruction Manual

__ TECNOEKA Srl ____________________________________________________ operating and instruction manual _

3.3 Unpacking the appliance

3.3 Unpacking the appliance
3.3 Unpacking the appliance 3.3 Unpacking the appliance
Before installing, remove the packaging. Packaging consists in a wooden pallet that the
appliance sits on and a cardboard box around it to provide protection. Make sure the appliance
has not incurred damage during transit; if it has, advise your dealer and/or carrier straight away.

3.4 Removing the protective film

3.4 Removing the protective film 3.4 Removing the protective film 3.4 Removing the protective film
Before using the appliance, carefully remove the special film protecting stainless steel parts. Do
not leave any glue residues on the surfaces. If necessary, remove them at once, using an
appropriate non-flammable solvent.

3.5 Disposing of packaging

3.5 Disposing of packaging 3.5 Disposing of packaging 3.5 Disposing of packaging
Dispose of packaging in strict compliance with the relevant regulations in force in the place
where the appliance is installed. The various materials making up the packaging (wood-paper-
cardboard-nylon-metal staples) must be sorted into like materials and disposed of through
relevant collection and recycling centres. Whatever the case, dispose of waste in an
environmentally responsible way.

3.6 Positioning

3.6 Positioning 3.6 Positioning 3.6 Positioning
Check the installation site, making sure that there is sufficient room to carry the appliance to
the site (check the size of door openings and corridors, if any). The dimensions of the appliance
without the pallet are given in Fig. 1. The appliance must be installed in a well ventilated room
with permanent vents.
The appliance must be positioned on a table or similar surface so that it is perfectly horizontal.
Never position it on the floor. Never position it on the floor Never position it on the floor Never position it on the floor
For safety reasons, we recommend using the manufacturer's specially designed stand;
otherwise, you will need to take into consideration the weight of the appliance. The maximum
work height, referring to the height of the top shelf, must be 1.6 metres off the floor. Once the
appliance is installed, stick on the relevant adhesive symbol (provided) at a height of 1.6 metres.
For easier access to the appliance and to encourage air to circulate around it, leave at least
50cm clearance between the left-hand side and the wall (or other appliance) and at least 10cm
clearance between the back and the wall and between the right-hand side and the wall (see Fig.
1). It is strictly forbidden to block the forced air vents on the left-hand side panel and on the
back, even partially or for short periods. Failure t
the manufacturer of the appliance of all liability and immediately void any warranty rights for the manufacturer of the appliance of all liability and immediately void any warranty rights for the manufacturer of the appliance of all liability and immediately void any warranty rights for the manufacturer of the appliance of all liability and immediately void any warranty rights for
said appliance, given that the conformity of its design and construction has been voluntarily said appliance,
said appliance, said appliance,
compromised.
For the same reason, do not place appliances with heat sources on the left side of the oven; if
room temperature on that side becomes excessive, the oven actually turns off automatically as a
safety measure.
If the appliance is installed near walls, shelves or suchlike, they must be of a non-flammable
variety or insensitive to heat; otherwise, they will need to be protected with a suitable flame-
retardant covering.
In this regard, you must comply with current regulations on the prevention of fire hazards.
T T T T he appliance is not suitable for recessed mounting. he appliance is not suitable for recessed mounting.
he appliance is not suitable for recessed mounting. he appliance is not suitable for recessed mounting.
_ page 8 _________________________________________________________________________________________
Failure to observe this specific prohibition shall relieve o observe this specific prohibition shall relieve
Failure t Failure t o observe this specific prohibition shall relieve o observe this specific prohibition shall relieve
