- Page 1 USE AND INSTRUCTION MANUAL MODD. EKF 411 P – EKF 416 P – EKF 464 P rev. 7 TECNOEKA S.r.l. Via Marco Polo, n.11 - 35010 Borgoricco (Padova) Italy Tel. +39.049.9300344 – +39.049.5791479 Fax +39.049.5794387 www.tecnoeka.com E-mail: info@tecnoeka.com...
-
Page 2: Eu Declaration Of Conformity
Purpose of the product Cooking food Model EKF 411 P – EKF 416 P – EKF 464 P TECNOEKA Srl declares that the mentioned above products meet the following safety regulations: Machine Directive 2006/42/EC; Electromagnetic compatibility directive 2014/30/EU TECNOEKA Srl declares that the mentioned above products meet the following harmonised standards: EN 60335-1 ;... - Page 3 Electric Ovens rev. 7____________________________________________________EKF 411 P – EKF 416 P – EKF 464 P Index 1. Technical service 2. General warnings 3. Technical specifications 4. Instructions for the installer 5. Use instructions (for the user) 6. Residual risks (for the user) 7.
-
Page 4: General Warnings
TECNOEKA Srl ______________________________________________________________ use and instruction manual 1. Technical service A technical check-up once or twice a year helps prolong the life of the appliance and guarantees better operation. Make sure that assistance is carried out solely and exclusively by qualified personnel. -
Page 5: Instructions For The Installer
Electric Ovens rev. 7____________________________________________________EKF 411 P – EKF 416 P – EKF 464 P 4. Instructions for the installer The following instructions are aimed at the qualified installer, to ensure that he carries out the installation, adjustment and maintenance operations as correctly as possible and according to current legal regulations. - Page 6 TECNOEKA Srl ______________________________________________________________ use and instruction manual (this electrical connection lay-out is located near the power supply terminal board ). Tighten the cable gripper and re-fit the rear side-panel of the appliance. The appliance must be connected to an equipotential system whose efficiency must first be checked according to current legal regulations.
-
Page 7: Oven Cooking
Electric Ovens rev. 7____________________________________________________EKF 411 P – EKF 416 P – EKF 464 P 7. How to use the control panel Fig. 1 Fig. 2 - Programmer indicator light - Temperature indicator light Programming cooking time - To run the oven, turn the programmer knob (Fig. 1) in line with symbol (continuous operation) or in line with the selected cooking time (up to 120 minutes). -
Page 8: Routine Cleaning And Maintenance
TECNOEKA Srl ______________________________________________________________ use and instruction manual Cooking desserts - Desserts require a very high temperature (usually from 150 to 200°C) and a pre-heated oven (about ten minutes). The oven door must not be opened until at least 3/4 of the cooking time has elapsed. -
Page 9: Informations To The Consumers
(on the rating plate on the rear panel). For any maintenance the user can contact Tecnoeka by calling the telephone numbers on the cover or going to www.tecnoeka.com. 12. Informations to the consumers... -
Page 10: Wiring Layout
TECNOEKA Srl ______________________________________________________________ use and instruction manual 13. Wiring layout CLIP FOR POWER SUPPLY TIMER PROGRAMMER DOOR MICRO-SWITCH SAFETY THERMOSTAT CONTROL THERMOSTAT R1-R3 CIRCULAR HEATING ELEMENT RADIAL MOTOR-VENTILATOR TANGENTIAL MOTOR-VENTILATOR B1-B2 CONTACTORS COIL LIGHTING BULB PROGRAMMER LIGHT BULB THERMOSTAT LIGHT BULB... - Page 11 / or purchaser to the seat of Tecnoeka Ltd. and vice versa. The warranty doesn't include also the oven's replacement costs and the related installation costs. The warranty excludes products purchased as used or purchased from third parties not connected or authorized by Tecnoeka.
- Page 12 TECNOEKA Srl ______________________________________________________________ use and instruction manual 15. Availability and supply of spare parts Tecnoeka Srl guarantees the supply of spare parts for a period not exceeding 24 months from the invoice date of the appliance purchased. After that date, availability of spare parts cannot be guaranteed.
